UH-PRC001-EN 42
Performance
Data
Table PD-5 (Continued) – Model P-L Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. (Capacities shown are for units with all Air Ports open)
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 260 F 300 F 340 F 380 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
50 143.1 5.90 98.9 .20 .27 186.0 7.67 110.6 .32 .43 228.8 9.43 122.2 .46 .61 271.7 11.20 133.9 .63 .83
60 128.9 4.43 95.0 .12 .16 171.7 5.90 106.7 .20 .26 214.6 7.37 118.3 .29 .39 257.4 8.84 130.0 .40 .54
202-P-L 80 100.4 2.59 87.3 .04 .06 143.3 3.69 99.0 .08 .11 186.1 4.80 110.6 .13 .17 229.0 5.90 122.3 .19 .25
CFM 3390 100 — — — — — 114.8 2.37 91.2 .04 .05 157.7 3.25 102.9 .06 .08 200.5 4.13 114.5 .10 .13
RPM 1100 120 — — — — — 86.4 1.48 83.5 .02 .02 129.2 2.22 95.1 .03 .04 172.1 2.96 106.8 .05 .07
HP 1/4 140 — — — — — — — — — — 100.8 1.48 87.4 .01 .02 143.6 2.11 99.0 .03 .04
160 — — — — — — — — — — — — — — — 115.2 1.48 91.3 .01 .02
50 188.2 7.76 98.5 .40 .53 240.6 9.92 109.2 .61 .81 292.9 12.07 119.9 .86 1.15 345.2 14.23 130.6 1.15 1.53
60 173.5 5.96 95.5 .24 .33 225.9 7.76 106.2 .39 .52 278.2 9.56 116.9 .56 .74 330.5 11.35 127.6 .76 1.01
252-P-L 80 144.2 3.71 89.5 .10 .14 196.5 5.06 100.2 .18 .24 248.8 6.41 110.9 .27 .36 301.2 7.76 121.6 .37 .50
FM 4507 100 114.8 2.37 83.5 .04 .06 167.1 3.44 94.2 .09 .12 219.5 4.52 104.9 .14 .19 271.8 5.60 115.6 .20 .27
RPM 1100 120 — — — — — 137.8 2.37 88.2 .04 .06 190.1 3.26 98.9 .08 .10 242.4 4.16 109.6 .12 .16
HP 1/4 140 — — — — — 108.4 1.60 82.2 .02 .03 160.7 2.37 92.9 .04 .06 213.1 3.14 103.6 .07 .09
160 — — — — — — — — — — 131.4 1.69 86.9 .02 .03 183.7 2.37 97.6 .04 .06
180 — — — — — — — — — — — — — — — 154.3 1.77 91.6 .02 .03
50 219.9 9.06 100.2 .53 .71 281.4 11.60 111.5 .82 1.09 342.8 14.13 122.7 1.16 1.54 404.3 16.66 133.9 1.55 2.06
60 202.4 6.95 97.0 .33 .43 263.9 9.06 108.3 .52 .69 325.3 11.18 119.5 .75 1.00 386.8 13.29 130.7 1.01 1.35
280-P-L 80 167.5 4.31 90.6 .13 .18 228.9 5.90 101.9 .23 .31 290.4 7.48 113.1 .36 .47 351.8 9.06 124.3 .50 .66
FM 5040 100 132.5 2.73 84.2 .06 .08 194.0 4.00 95.5 .11 .15 255.4 5.26 106.7 .19 .25 316.9 6.53 117.9 .27 .36
RPM 1100 120 — — — — — 159.0 2.73 89.1 .06 .08 220.5 3.79 100.3 .10 .14 281.9 4.84 111.6 .16 .21
HP 1/2 140 — — — — — 124.1 1.83 82.7 .03 .04 185.5 2.73 93.9 .06 .07 247.0 3.64 105.2 .09 .12
160 — — — — — — — — — — 150.6 1.94 87.5 .03 .04 212.0 2.73 98.8 .05 .07
180 — — — — — — — — — — — — — — — 177.1 2.03 92.4 .03 .04
200 — — — — — — — — — — — — — — — 142.2 1.46 86.0 .02 .02
50 256.5 10.57 101.5 .71 .94 328.5 13.54 113.1 1.09 1.46 400.5 16.51 124.8 1.55 2.06 472.5 19.48 136.4 2.07 2.76
60 235.9 8.10 98.1 .43 .58 307.8 10.57 109.8 .69 .92 379.8 13.05 121.4 1.00 1.33 451.8 15.52 133.1 1.36 1.81
80 194.5 5.01 91.5 .18 .24 266.5 6.87 103.1 .31 .41 338.5 8.72 114.7 .47 .63 410.5 10.57 126.4 .66 .89
336-P-L 100 153.2 3.16 84.8 .08 .10 225.2 4.64 96.4 .15 .20 297.1 6.12 108.0 .25 .33 369.1 7.61 119.7 .36 .48
CFM 5700 120 111.8 1.92 78.1 .03 .04 183.8 3.16 89.7 .07 .10 255.8 4.39 101.4 .13 .18 327.8 5.63 113.0 .21 .28
RPM 1140 140 — — — — — 142.5 2.10 83.0 .04 .05 214.5 3.16 94.7 .07 .10 286.4 4.22 106.3 .12 .16
HP 3/4 160 — — — — — — — — — — 173.1 2.23 88.0 .04 .05 245.1 3.16 99.6 .07 .10
180 — — — — — — — — — — — — — — — 203.8 2.33 92.9 .04 .05
200 — — — — — — — — — — — — — — — 162.4 1.67 86.3 .02 .03
