37 UH-PRC001-EN
Performance
Data
Table PD-4 (Continued) – Model P Unit Heater Hot Water Capacities – 60°F Ent. Air Temp.
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 260 F 300 F 340 F 380 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
50 341.8 14.09 111.3 .88 1.19 437.9 18.05 125.7 1.37 1.84 534.0 22.01 140.2 1.94 2.61 630.0 25.97 154.6 2.61 3.50
60 314.1 10.79 107.1 .54 .72 410.2 14.09 121.6 .86 1.16 506.2 17.39 136.0 1.25 1.68 602.3 20.69 150.4 1.70 2.28
80 258.6 6.66 98.8 .22 .30 354.7 9.14 113.2 .39 .52 450.8 11.61 127.7 .59 .79 546.9 14.09 142.1 .83 1.12
384-P 100 203.2 4.19 90.5 .09 .13 299.3 6.17 104.9 .19 .25 395.4 8.15 119.3 .31 .41 491.4 10.13 133.8 .45 .60
CFM 6140 120 147.8 2.54 82.2 .04 .05 243.8 4.19 96.6 .09 .12 339.9 5.84 111.0 .17 .22 436.0 7.49 125.4 .26 .35
RPM 1140 140 — — — — — 188.4 2.77 88.3 .04 .06 284.5 4.19 102.7 .09 .12 380.6 5.60 117.1 .15 .20
HP 3/4 160 — — — — — — — — — — 229.1 2.95 94.4 .05 .06 325.1 4.19 108.8 .09 .10
180 — — — — — — — — — — 173.6 1.99 86.1 .02 .03 269.7 3.09 100.5 .05 .07
200 — — — — — — — — — — — — — — — 214.3 2.21 92.2 .03 .04
50 451.9 18.63 111.9 1.49 2.03 576.8 23.78 126.3 2.28 3.11 701.7 28.92 140.6 3.21 4.37 826.6 34.07 155.0 4.28 5.82
60 417.4 14.34 108.0 .92 1.25 542.3 18.63 122.3 1.45 1.98 667.2 22.92 136.7 2.09 2.84 792.1 27.21 151.0 2.81 3.83
80 348.3 8.97 100.0 .39 .53 473.2 12.19 114.4 .66 .90 598.1 15.41 128.7 1.00 1.36 723.0 18.63 143.1 1.39 1.90
500-P 100 279.3 5.76 92.1 .17 .23 404.2 8.33 106.5 33 .45 529.1 10.90 120.8 .53 .72 654.0 13.48 135.2 .77 1.04
CFM 8020 120 210.3 3.61 84.2 .07 .10 335.2 5.76 98.5 .17 .23 460.1 7.90 112.9 .29 .40 585.0 10.05 127.2 .45 .61
RPM 1160 140 — — — — — 266.1 3.92 90.6 .08 .11 391.0 5.76 104.9 .16 .22 515.9 7.60 119.3 .27 .36
HP 1-1/2 160 — — — — — 197.1 2.54 82.7 .04 .05 322.0 4.15 97.0 .09 .12 446.9 5.76 111.4 .16 .22
180 — — — — — — — — — — 253.0 2.90 89.1 .05 .06 377.9 4.33 103.4 .10 .13
200 — — — — — — — — — — — — — — — 308.8 3.18 95.5 .05 .07
50 529.9 21.84 111.7 1.21 1.58 676.0 27.86 125.9 1.86 2.42 822.1 33.89 140.2 2.61 3.41 968.2 39.91 154.4 3.48 4.54
60 489.7 16.82 107.8 .75 .98 635.8 21.84 122.0 1.18 1.54 781.9 26.86 136.3 1.70 2.22 928.1 31.88 150.5 2.29 2.99
80 409.4 10.55 99.9 .32 .41 555.5 14.31 114.2 .54 .71 701.6 18.08 182.4 .82 1.07 847.8 21.84 142.7 1.14 1.48
600-P 100 329.1 6.78 92.1 .14 .18 475.2 9.79 106.3 .27 .35 621.3 12.81 120.6 .43 .56 767.5 15.82 134.8 .63 .82
CFM 9450 120 248.8 4.27 84.3 .06 .08 394.9 6.78 98.5 .14 .18 541.0 9.29 112.8 .24 .31 687.1 11.80 127.0 .36 .48
RPM 1160 140 — — — — — 314.6 4.63 90.7 .07 .09 460.7 6.78 104.9 .13 .18 606.8 8.93 119.2 .22 .29
HP 1-1/2 160 — — — — — 234.3 3.02 82.8 .03 .04 380.4 4.90 97.1 .07 .10 526.5 6.78 111.4 .13 .17
180 — — — — — — — — — — 300.1 3.44 89.3 .04 .05 446.2 5.11 103.5 .08 .10
200 — — — — — — — — — — — — — — — 365.9 3.77 95.7 .04 .06
50 638.0 26.30 113.5 1.36 1.85 814.1 33.56 128.2 2.08 2.85 990.3 40.82 143.0 2.93 4.02 1166.4 48.08 157.7 3.89 5.36
60 589.4 20.25 109.4 .84 1.14 765.6 26.20 124.1 1.32 1.81 941.7 32.35 138.9 1.90 2.61 1117.8 38.40 153.7 2.56 3.52
80 492.3 12.68 101.2 .35 .48 668.5 17.22 116.0 .61 .83 844.6 21.76 130.8 .91 1.25 1020.7 26.30 145.5 1.27 1.74
720-P 100 395.2 8.15 93.1 .16 .21 571.4 11.78 107.9 .30 .41 747.5 15.41 122.6 .48 .66 923.6 19.04 137.4 .70 .96
CFM 11,000 120 298.1 5.12 85.0 .07 .09 474.2 8.15 99.7 .15 .21 650.4 11.17 114.5 .27 .36 826.5 14.20 129.3 .41 .56
RPM 1165 140 — — — — — 377.1 5.55 91.6 .08 .10 553.3 8.15 106.4 .15 .20 729.4 10.74 121.1 .24 .33
HP 3 160 — — — — — 280.0 3.61 83.5 .03 .05 456.2 5.88 98.2 .08 .11 632.3 8.15 113.0 .15 .20
180 — — — — — — — — — — 359.1 4.11 90.1 .04 .06 535.2 6.13 104.8 .09 .12
200 — — — — — — — — — — — — — — — 438.1 4.51 96.7 .05 .07
