35 UH-PRC001-EN
Performance
Data
Table PD-4 – Model P Unit Heater Hot Water Capacities – 60°F Ent. Air Temp.
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 180 F 200 F 220 F 240 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
10 131.6 27.11 97.9 3.69 4.90 156.2 32.20 105.0 5.02 6.66 — — — — — — — — — —
15 123.3 16.94 95.5 1.53 2.03 148.0 20.33 102.6 2.12 2.81 172.7 23.72 109.7 2.79 3.70 197.3 27.11 116.8 3.54 4.70
202-P 20 115.1 11.86 93.1 .78 1.04 139.7 14.40 100.2 1.11 1.47 164.4 16.94 107.4 1.48 1.97 189.1 19.49 114.5 1.90 2.52
CFM 3200 25 106.8 8.80 90.8 .45 .60 131.5 10.84 97.9 .65 .87 156.2 12.87 105.0 .89 1.18 180.8 14.91 112.1 1.15 1.53
RPM 1100 30 98.5 6.77 88.4 .28 .37 123.2 8.47 95.5 .41 .55 147.9 10.16 102.6 .57 .76 172.6 11.86 109.7 .75 1.00
HP 1/4 40 82.0 4.23 83.6 .11 .15 106.7 5.50 90.7 .18 .25 131.4 6.77 97.8 .27 .36 156.1 8.04 105.0 .36 .48
50 65.5 2.70 78.9 .05 .07 90.2 3.72 86.0 .09 .12 114.9 4.74 93.1 .14 .18 139.6 5.75 100.2 .19 .26
60 — — — — — 73.7 2.53 81.2 .04 .06 98.4 3.38 88.3 .07 .10 123.1 4.23 95.4 .11 .15
10 166.9 34.40 97.0 6.75 8.98 — — — — — — — — — — — — — — —
15 158.1 21.73 95.0 2.86 3.82 188.9 25.95 101.8 3.92 5.22 219.6 30.17 108.6 5.12 6.80 250.3 34.40 115.4 6.45 8.57
252-P 20 149.4 15.40 93.1 1.51 2.01 180.1 18.56 99.9 2.10 2.80 210.9 21.73 106.7 2.77 3.69 241.6 24.90 113.5 3.52 4.69
CFM 4162 25 140.7 11.60 91.2 .89 1.19 171.4 14.13 98.0 1.26 1.68 202.1 16.66 104.8 1.69 2.25 232.9 19.20 111.6 2.17 2.89
RPM 1100 30 131.9 9.06 89.2 .57 .75 162.7 11.18 96.0 .82 1.09 193.4 13.29 102.8 1.11 1.48 224.1 15.40 109.6 1.44 1.92
HP 1/4 40 114.5 5.90 85.3 .26 .34 145.2 7.48 92.2 .39 .52 175.9 9.06 99.0 .55 .73 206.6 10.65 105.8 .73 .97
50 97.0 4.00 81.5 .12 .17 127.7 5.26 88.3 .20 .27 158.4 6.53 95.1 .30 .40 189.2 7.80 101.9 .41 .54
60 79.5 2.73 77.6 .06 .08 110.2 3.79 84.4 .11 .15 141.0 4.84 91.2 .17 .23 171.7 5.90 98.0 .24 .32
15 180.4 24.78 97.5 3.66 4.88 215.4 29.60 104.8 5.02 6.67 250.5 34.42 112.1 6.55 8.71 — — — — —
20 170.3 17.55 95.4 1.93 2.57 205.4 21.17 102.7 2.68 3.57 240.5 24.78 110.0 3.54 4.72 275.6 28.40 117.3 4.51 6.00
280-P 25 160.2 13.21 93.3 1.14 1.52 195.3 16.10 100.6 1.61 2.15 230.4 19.00 107.9 2.16 2.88 265.5 21.89 115.2 2.77 3.69
CFM 4430 30 150.2 10.32 91.2 .72 .96 185.3 12.73 98.5 1.04 1.39 220.4 15.14 105.8 1.42 1.89 255.4 17.55 113.1 1.84 2.45
RPM 1100 40 130.1 6.70 87.1 .32 .43 165.1 8.51 94.4 .49 .66 200.2 10.32 101.7 .70 .93 235.3 12.12 109.0 .92 1.23
HP 1/2 50 109.9 4.53 82.9 .16 .21 145.0 5.98 90.2 .26 .34 180.1 7.42 97.5 .38 .50 215.2 8.87 104.8 .52 .69
60 89.8 3.08 78.7 .08 .10 124.9 4.29 86.0 .14 .19 160.0 5.50 93.3 .22 .29 195.1 6.70 100.6 .31 .41
15 213.4 29.32 97.7 5.02 6.68 254.9 35.03 105.1 6.88 9.14 — — — — — — — — — —
20 201.3 20.75 95.6 2.63 3.51 242.9 25.03 103.0 3.67 4.89 284.5 29.32 110.3 4.86 6.46 326.0 33.60 117.7 6.18 8.22
336-P 25 189.3 15.61 93.5 1.55 2.07 230.9 19.04 100.8 2.21 2.94 272.5 22.46 108.2 2.95 3.93 314.0 25.89 115.6 3.80 5.05
CFM 5210 30 177.3 12.18 91.4 .98 1.31 218.9 15.04 98.7 1.42 1.90 260.5 17.89 106.1 1.93 2.58 302.0 20.75 113.4 2.51 3.35
RPM 1140 40 153.3 7.90 87.1 .44 .59 194.9 10.04 94.5 .67 .90 236.4 12.18 101.8 .95 1.26 278.0 14.32 109.2 1.26 1.68
HP 3/4 50 129.3 5.33 82.9 .21 .28 170.8 7.04 90.2 .35 .47 212.4 8.76 97.6 .51 .69 254.0 10.47 104.9 .71 .94
60 105.2 3.61 78.6 .10 .14 146.8 5.04 86.0 .19 .25 188.4 6.47 93.3 .29 .39 229.9 7.90 100.7 .42 .56
15 246.7 33.89 97.0 4.81 6.46 294.7 40.49 104.2 6.60 8.86 — — — — — — — — — —
20 232.8 23.99 94.9 2.52 3.39 280.3 28.94 102.2 3.52 4.73 328.9 33.89 109.4 4.66 6.26 376.9 38.84 116.6 5.94 7.97
384-P 25 218.9 18.05 92.9 1.48 2.00 267.0 22.01 100.1 2.11 2.84 315.0 25.97 107.3 2.83 3.80 363.1 29.93 114.5 3.65 4.89
CFM 6140 30 205.1 14.09 90.8 .94 1.26 253.1 17.39 98.0 1.36 1.83 301.2 20.69 105.2 1.85 2.49 349.2 23.99 112.4 2.41 3.24
RPM 1140 40 177.4 9.14 86.6 .42 .57 225.4 11.61 93.8 .64 .87 273.4 14.09 101.0 .91 1.22 321.5 16.56 108.3 1.21 1.62
HP 3/4 50 149.6 6.17 82.5 .20 .27 197.7 8.15 89.7 .33 .45 245.7 10.13 96.9 .49 .66 293.8 12.11 104.1 .67 .91
60 121.9 4.19 78.3 .10 .13 170.0 5.84 85.5 .18 .24 218.0 7.49 92.7 .28 .38 266.0 9.14 99.9 .40 .54
20 305.7 31.50 95.1 4.19 5.71 368.1 37.93 102.3 5.81 7.91 — — — — — — — — — —
500-P 25 288.4 23.78 93.1 2.49 3.39 350.8 28.92 100.3 3.52 4.79 413.3 34.07 107.5 4.69 6.38 475.7 39.22 114.7 6.00 8.17
CFM 8020 30 271.1 18.63 91.2 1.59 2.16 333.6 22.92 98.3 2.29 3.11 396.0 27.21 105.5 3.09 4.20 458.5 31.50 112.7 3.99 5.43
RPM 1160 40 236.6 12.19 87.2 .73 .99 299.1 15.41 94.4 1.10 1.49 361.5 18.63 101.5 1.53 2.09 424.0 21.84 108.7 2.03 2.76
HP 1-1/2 50 202.1 8.33 83.2 .36 .49 264.6 10.90 90.4 .58 .79 327.0 13.48 97.6 .84 1.15 389.4 16.05 104.8 1.15 1.56
60 167.6 5.76 79.3 .18 .25 230.0 7.90 86.4 .32 .44 292.5 10.05 93.6 .49 .67 354.9 12.19 100.8 .69 .94
15 378.1 51.96 96.9 6.43 8.40 451.2 62.00 104.0 8.78 11.46 — — — — — — — — — —
20 358.1 36.90 94.9 3.41 4.45 431.1 44.43 102.0 4.72 6.17 504.2 51.96 109.2 6.22 8.12 — — — — —
600-P 25 338.0 27.86 93.0 2.02 2.65 411.1 33.89 100.1 2.86 3.73 484.1 39.91 107.2 3.81 4.97 557.2 45.93 114.3 4.88 6.36
CFM 9450 30 317.9 21.84 91.0 1.29 1.69 391.0 26.86 98.1 1.86 2.43 464.0 31.88 105.3 2.51 3.28 537.1 36.90 112.4 3.24 4.24
RPM 1160 40 277.8 14.31 87.1 .59 .78 350.8 18.08 94.2 .89 1.17 423.9 21.84 101.3 1.25 1.63 496.9 25.61 108.5 1.65 2.15
HP 1-1/2 50 237.6 9.79 83.2 .29 .39 310.7 12.81 90.3 .47 .62 383.7 15.82 97.4 .69 .90 456.8 18.83 104.6 .93 1.22
60 197.4 6.78 79.3 .15 .20 270.5 9.29 86.4 .26 .34 343.6 11.80 93.5 .40 .53 416.6 14.31 100.6 .56 .74
15 455.6 62.60 98.2 7.21 9.88 — — — — — — — — — — — — — — —
20 431.3 44.45 96.1 3.82 5.22 519.4 53.52 103.5 5.29 7.25 607.5 62.60 110.9 6.97 9.56 — — — — —
720-P 25 407.1 33.56 94.1 2.27 3.10 495.1 40.82 101.5 3.20 4.38 583.2 48.08 108.9 4.27 5.85 671.3 55.34 116.2 5.46 7.49
CFM 11,000 30 382.8 26.30 92.1 1.45 1.97 470.9 32.35 99.5 2.08 2.84 558.9 38.40 106.8 2.81 3.85 647.0 44.45 114.2 3.63 4.98
RPM 1165 40 334.2 17.22 88.0 .66 .90 422.3 21.76 95.4 1.00 1.36 510.4 26.30 102.8 1.40 1.91 598.4 30.83 110.1 1.85 2.52
HP 3 50 285.7 11.78 83.9 .33 .45 373.7 15.41 91.3 .53 .72 461.8 19.04 98.7 .77 1.05 549.9 22.67 106.1 1.05 1.43
60 237.1 8.15 79.9 .17 .23 325.2 11.17 87.2 .29 .40 413.3 14.20 94.6 .45 .61 501.3 17.22 102.0 .63 .86
See Table SP-12 for abbreviations.
