Model p-totally enclosed, Model p-explosion proof, Electric power – Trane UH-PRC001-EN User Manual
Page 45
45
UH-PRC001-EN
Electric
Power
Table EP-4 Electric Power — Model P Unit Heater — Motor
Accessory
Model
Motor
Operating
MAX
Number
Type
Voltage
AMP
MCA
FUSE
HP
RPM
42
Totally Enclosed
115/60/1
1.23**
1.6
15
1/40*
1550
64,80
Totally Enclosed
115/60/1
2.1
2.6
15
1/20*
1550
102
Totally Enclosed
115/60/1
1.2**
1.5
15
1/8*
1070
122,146,166
Totally Enclosed
115/60/1
2.3**
2.9
15
1/6
1100
202
Totally Enclosed
115/60/1
3.6**
4.5
15
1/4
1100
252
Totally Enclosed
115/60/1
3.6**
4.5
15
1/4
1100
280
Totally Enclosed
115/60/1
5.4**
6.8
15
1/2
1100
42
Totally Enclosed
208-230/460/60/3
0.98-1.1/0.55
1.2-1.4/0.7
15-15/15
1/6
1140
64,80
Totally Enclosed
208-230/460/60/3
0.98-1.1/0.55
1.2-1.4/0.7
15-15/15
1/6
1140
102
Totally Enclosed
208-230/460/60/3
0.98-1.1/0.55
1.2-1.4/0.7
15-15/15
1/6
1140
122,146,166
Totally Enclosed
208-230/460/60/3
0.98-1.1/0.55
1.2-1.4/0.7
15-15/15
1/6
1140
202
Totally Enclosed
208-230/460/60/3
1.2-1.4/0.7
1.5-1.8/0.9
15-15/15
1/4
1140
252
Totally Enclosed
208-230/460/60/3
1.2-1.4/0.7
1.5-1.8/0.9
15-15/15
1/4
1140
280
Totally Enclosed
208-230/460/60/3
1.8-2.0/1.0
2.3-2.5/1.3
15-15/15
1/2
1140
336,384
Totally Enclosed
208-230/460/60/3
3.1-3.2/1.6
3.9-4.0/2.0
15-15/15
3/4
1140
500,600
Totally Enclosed
208-230/460/60/3
5.3-5.0/2.5
6.6-6.3/3.1
15-15/15
1-½
1160
720
Totally Enclosed
208-230/460/60/3
9.9-9.8/4.9
12.4-12.3/6.1
20-20/15
3
1165
*Optional variable speed switch is available.
**These motors have automatic thermal overload protection or impedance protection.
CAUTION: Select appropriate AMP, MCA, and MAX FUSE for the multiple voltage motors. For example, the AMP, MCA, and MAX FUSE for Model 720 with a 230 volt Totally Enclosed motor
is 9.8, 12.3, and 20 respectively.
Accessory
Model
Motor
Operating
MAX
Number
Type
Voltage
AMP
MCA
FUSE
HP
RPM
Explosion Proof
42
with Thermal Overload
115/60/1
3.8
4.8
15
1/6
1140
Explosion Proof
64,80
with Thermal Overload
115/60/1
3.8
4.8
15
1/6
1140
Explosion Proof
102
with Thermal Overload
115/60/1
3.8
4.8
15
1/6
1140
Explosion Proof
122,146,166
with Thermal Overload
115/60/1
3.8
4.8
15
1/6
1140
Explosion Proof
202
with Thermal Overload
115/60/1
4.4
5.5
15
1/4
1140
Explosion Proof
252
with Thermal Overload
115/60/1
4.4
5.5
15
1/4
1140
Explosion Proof
280
with Thermal Overload
115/60/1
7.8
9.8
20
1/2
1140
Explosion Proof
42
with Thermal Overload
208-230/460/60/3
1.0-1.0/0.5
1.3-1.3/0.6
15-15/15
1/6
1140
Explosion Proof
64,80
with Thermal Overload
208-230/460/60/3
1.0-1.0/0.5
1.3-1.3/0.6
15-15/15
1/6
1140
Table EP-5 Electric Power — Model P Unit Heater — Motor
