39 UH-PRC001-EN
Performance
Data
Table PD-5 (Continued) – Model P-L Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. (Capacities shown are for units with all Air Ports open)
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 180 F 200 F 220 F 240 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
10 53.6 11.04 88.2 1.04 1.36 63.7 13.13 93.5 1.43 1.86 73.8 15.22 98.8 1.87 2.43 84.0 17.31 104.2 2.36 3.07
15 50.0 6.86 86.3 .43 .56 60.1 8.26 91.6 .59 .78 70.2 9.65 96.9 .79 1.03 80.4 11.04 102.3 1.01 1.31
102-P-L 20 46.3 4.77 84.4 .22 .23 56.5 5.82 89.7 .31 .40 66.6 6.86 95.0 .41 .54 76.7 7.91 100.4 .53 .70
CFM 1752 25 42.7 3.52 82.5 .12 .16 52.9 4.36 87.8 .18 .23 63.0 5.19 93.1 .24 .32 73.1 6.03 98.5 .32 .42
RPM 1070 30 39.1 2.69 80.6 .07 .10 49.2 3.38 85.9 .11 .15 59.4 4.08 91.2 .16 .20 69.5 4.77 96.6 .21 .27
HP 1/8 40 31.9 1.64 76.8 .03 .04 42.0 2.16 82.1 .05 .06 52.1 2.69 87.4 .07 .09 62.3 3.21 92.8 .10 .13
50 — — — — — 34.8 1.43 78.3 .02 .03 44.9 1.85 83.6 .04 .05 55.0 2.27 88.9 .05 .07
60 — — — — — — — — — — 37.6 1.29 79.8 .02 .02 47.8 1.64 85.1 .03 .04
10 45.9 9.45 88.2 .78 1.02 54.5 11.24 93.5 1.06 1.39 63.2 13.02 98.8 1.39 1.81 71.8 14.80 104.2 1.75 2.28
15 42.8 5.89 86.3 .32 .42 51.5 7.07 91.7 .44 .58 60.1 8.26 97.0 .59 .77 68.8 9.45 102.3 .75 .98
102-P-L 20 39.8 4.10 84.5 .16 .21 48.5 4.99 89.8 .23 .30 57.1 5.89 95.1 .31 .40 65.8 6.78 100.4 .40 .52
CFM 1499 25 36.8 3.03 82.6 .09 .12 45.4 3.75 87.9 .13 .18 54.1 4.46 93.3 .18 .24 62.7 5.17 98.6 .24 .31
RPM 850 30 33.8 2.32 80.8 .06 .07 42.4 2.91 86.1 .08 .11 51.1 3.51 91.4 .12 .15 59.7 4.10 96.7 .16 .20
HP 1/8 40 — — — — — 36.4 1.87 82.4 .04 .05 45.0 2.32 87.7 .05 .07 53.7 2.76 93.0 .07 .10
50 — — — — — — — — — — 39.0 1.61 84.0 .03 .04 47.6 1.96 89.3 .04 .05
60 — — — — — — — — — — — — — — — 41.6 1.43 85.5 .02 .03
10 70.3 14.49 89.7 1.75 2.28 83.7 17.24 95.4 2.40 3.12 97.0 19.99 101.0 3.14 4.08 110.4 22.74 106.7 3.97 5.15
15 65.5 8.99 87.7 .71 .93 78.8 10.83 93.3 .99 1.30 92.1 12.66 99.0 1.32 1.72 105.5 14.49 104.6 1.69 2.19
122-P-L 20 60.6 6.24 85.6 .36 .47 73.9 7.62 91.3 .51 .67 87.3 8.99 96.9 .69 .90 100.6 10.37 102.5 .89 1.16
CFM 2180 25 55.7 4.59 83.6 .20 .26 69.1 5.69 89.2 .30 .39 82.4 6.79 94.8 .41 .53 95.8 7.89 100.5 .53 .70
RPM 1100 30 50.9 3.49 81.5 .12 .16 64.2 4.41 87.1 .18 .24 77.6 5.33 92.8 .26 .34 90.9 6.24 98.4 .34 .45
HP 1/6 40 41.1 2.12 77.4 .05 .06 54.5 2.81 83.0 .08 .10 67.8 3.49 88.7 .12 .15 81.2 4.18 94.3 .16 .21
50 31.4 1.29 73.3 .02 .02 44.8 1.84 78.9 .04 .05 58.1 2.39 84.6 .06 .08 71.4 2.94 90.2 .08 .11
60 — — — — — — — — — — 48.4 1.66 80.4 .03 .04 61.7 2.12 86.1 .05 .06
10 80.4 16.56 91.4 2.15 2.89 95.4 19.66 97.3 2.92 3.92 110.4 22.76 103.1 3.78 5.08 125.5 25.86 109.0 4.75 6.37
15 75.4 10.36 89.5 .89 1.20 90.5 12.43 95.3 1.23 1.66 105.5 14.50 101.2 1.62 2.18 120.5 16.56 107.1 2.05 2.76
146-P-L 20 70.5 7.26 87.5 .46 .62 85.5 8.81 93.4 .65 .87 100.6 10.36 99.3 .87 1.16 115.6 11.91 105.0 1.11 1.49
CFM 2360 25 65.5 5.40 85.6 .27 .36 80.6 6.64 91.5 .38 .52 95.6 7.88 97.3 .52 .70 110.7 9.12 103.2 .67 .90
RPM 1100 30 60.6 4.16 83.7 .16 .22 75.6 5.20 89.5 .24 .33 90.7 6.23 95.4 .34 .45 105.7 7.26 101.3 .44 .59
HP 1/6 40 50.7 2.61 79.8 .07 .09 65.8 3.39 85.7 .11 .15 80.8 4.16 91.6 .16 .21 95.8 4.94 97.4 .21 .29
50 40.9 1.68 76.0 .03 .04 55.9 2.30 81.8 .05 .07 70.9 2.92 87.7 .08 .11 86.0 3.54 93.6 .12 .16
60 — — — — — 46.0 1.58 78.0 .03 .04 61.1 2.10 83.8 .04 .06 76.1 2.61 89.7 .07 .09
10 94.6 19.50 89.9 1.98 2.64 112.3 23.15 95.4 2.70 3.58 130.0 26.80 101.0 3.50 4.65 147.7 30.44 106.6 4.40 5.83
15 88.8 12.21 88.0 .82 1.10 106.5 14.64 93.6 1.14 1.52 124.2 17.07 99.2 1.50 1.99 141.9 19.50 104.8 1.90 2.52
166-P-L 20 83.0 8.56 86.2 .43 .57 100.7 10.38 91.8 .60 .80 118.4 12.21 97.4 .80 1.06 136.1 14.03 103.0 1.02 1.36
CFM 2920 25 77.3 6.37 84.4 .25 .33 95.0 7.83 90.0 .35 .47 112.7 9.29 95.6 .48 .64 130.4 10.75 101.1 .62 .83
RPM 1100 30 71.5 4.91 82.6 .15 .20 89.2 6.13 88.1 .22 .30 106.9 7.34 93.7 .31 .41 124.6 8.56 99.3 .41 .54
HP 1/6 40 59.9 3.09 78.9 .06 .09 77.6 4.00 84.5 .10 .14 95.3 4.91 90.1 .15 .20 113.0 5.82 95.7 .20 .26
50 — — — — — 66.0 2.72 80.8 .05 .07 83.7 3.45 86.4 .08 .10 101.4 4.18 92.0 .11 .14
60 — — — — — 54.5 1.87 77.2 .02 .03 72.2 2.48 82.8 .04 .06 89.9 3.09 88.4 .06 .08
See Table SP-12 for abbreviations.
