31 UH-PRC001-EN
Performance
Data
Table PD-2 (Continued) – Model S Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. Hot Water with Turbulators and 132 Fin Series
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 260 F 300 F 340 F 380 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
60 156.9 5.39 123.8 1.98 2.36 199.2 6.84 141.0 2.75 3.28 — — — — — — — — — —
168-W2 80 138.8 3.57 116.4 1.02 1.22 181.0 4.66 133.6 1.49 1.77 — — — — — — — — — —
CFM 2267 100 120.6 2.49 109.9 .57 .68 162.9 3.36 126.2 .88 1.05 205.2 4.23 143.4 1.20 1.43 — — — — —
RPM 1100 120 102.5 1.76 101.7 .33 .39 144.7 2.49 118.8 .55 .65 187.0 3.21 136.0 .78 .93 — — — — —
HP 1/6 140 84.3 1.24 94.3 .19 .23 126.6 1.86 111.5 .35 .41 168.9 2.49 128.7 .52 .62 211.1 3.11 145.8 .70 .83
160 66.2 .85 86.9 .11 .13 108.5 1.40 104.1 .22 .26 150.7 1.94 121.3 .35 .42 193.0 2.49 138.5 .49 .59
180 48.1 .55 79.5 .05 .06 90.3 1.03 96.7 .14 .16 132.6 1.52 113.9 .24 .28 174.9 2.00 131.1 .35 .42
50 179.7 7.41 121.6 3.31 3.95 225.4 9.29 137.2 4.51 5.38 — — — — — — — — — —
60 169.8 5.83 118.2 2.25 2.69 215.6 7.41 133.9 3.13 3.73 — — — — — — — — — —
186-W2 80 150.2 3.87 111.5 1.17 1.39 195.9 5.05 127.1 1.69 2.02 241.7 6.23 142.8 2.24 2.67 — — — — —
CFM 2690 100 130.6 2.69 104.7 .65 .78 176.3 3.63 120.4 1.00 1.20 222.1 4.58 136.1 1.37 1.63 — — — — —
RPM 1100 120 110.9 1.90 98.0 .38 .45 156.7 2.69 113.7 .62 .74 202.4 3.48 129.4 .89 1.06 248.2 4.26 145.0 1.16 1.38
HP 1/4 140 91.3 1.34 91.3 .21 .26 137.0 2.02 106.9 .39 .47 182.8 2.69 122.6 .59 .71 228.5 3.36 138.3 .80 .95
160 71.6 .92 84.5 .12 .14 117.4 1.51 100.2 .25 .30 163.1 2.10 115.9 .40 .48 208.9 2.69 131.6 .56 .67
180 52.0 .60 77.8 .06 .07 97.7 1.12 93.5 .15 .18 143.5 1.64 109.2 .27 .32 189.2 2.17 124.8 .40 .48
60 222.6 7.65 124.1 .88 1.05 284.4 9.77 141.9 1.23 1.47 — — — — — — — — — —
80 193.8 4.99 115.8 .44 .53 255.6 6.59 133.6 .65 .78 — — — — — — — — — —
230-W2 100 165.1 3.40 107.5 .24 .28 226.9 4.68 125.3 .38 .45 288.6 5.95 143.1 .53 .63 — — — — —
CFM 3200 120 136.3 2.34 99.3 .13 .16 198.1 3.40 117.1 .23 .27 259.9 4.46 134.8 .33 .40 — — — — —
RPM 1100 140 107.5 1.58 91.0 .07 .08 169.3 2.49 108.0 .14 .17 231.1 3.40 126.6 .22 .26 292.9 4.31 144.4 .30 .36
HP 1/4 160 78.8 1.01 82.7 .03 .04 140.6 1.81 100.5 .08 .10 202.3 2.61 118.3 .14 .17 264.1 3.40 136.1 .21 .25
180 50.0 .57 74.4 .01 .02 111.8 1.28 92.2 .05 .06 173.6 1.99 110.0 .09 .11 235.4 2.69 127.8 .14 .17
50 261.7 10.79 121.3 1.54 1.83 330.2 13.61 137.4 2.11 2.52 — — — — — — — — — —
60 245.6 8.44 117.6 1.03 1.23 314.0 10.79 133.6 1.45 1.73 — — — — — — — — — —
260-W2 80 213.4 5.50 110.0 .52 .62 281.8 7.26 126.0 .77 .92 350.3 9.02 142.1 1.03 1.23 — — — — —
CFM 3933 100 181.2 3.73 102.5 .28 .33 249.6 5.14 118.5 .44 .53 318.1 6.56 134.5 .62 .74 — — — — —
RPM 1100 120 148.9 2.56 94.9 .15 .18 217.4 3.73 110.9 .27 .32 285.8 4.91 127.0 .39 .47 354.3 6.08 143.0 .52 .62
HP 1/2 140 116.7 1.72 87.3 .08 .10 185.2 2.73 103.4 .16 .19 253.6 3.73 119.4 .25 .30 322.1 4.74 135.5 .35 .42
160 84.5 1.09 79.8 .04 .05 152.9 1.97 95.8 .10 .11 221.4 2.85 111.9 .17 .20 289.8 3.73 127.9 .24 .29
180 52.3 .60 72.2 .02 .02 120.7 1.38 88.3 .05 .06 189.2 2.17 104.3 .11 .13 257.6 2.95 120.4 .17 .20
60 323.1 11.10 128.5 2.14 2.55 — — — — — — — — — — — — — — —
80 286.7 7.39 120.7 1.11 1.33 373.2 9.61 139.1 1.61 1.92 — — — — — — — — — —
320-W2 100 250.3 5.16 113.0 .63 .75 336.8 6.94 131.4 .96 1.14 — — — — — — — — — —
CFM 4350 120 213.9 3.67 105.3 .37 .44 300.4 5.16 123.0 .60 .71 386.8 6.64 142.0 .85 1.01 — — — — —
RPM 1100 140 177.5 2.61 97.6 .21 .25 264.0 3.89 115.9 .38 .46 350.4 5.16 134.3 .57 .68 — — — — —
HP 1/2 160 141.1 1.82 89.9 .12 .14 227.6 2,93 108.2 .25 .29 314.1 4.05 126.5 .39 .46 400.5 5.16 144.9 .54 .64
180 104.8 1.20 82.2 .06 .08 191.2 2.19 100.5 .15 .18 277.7 3.18 118.8 .27 .32 364.1 4.17 137.1 .39 .46
50 382.2 15.76 123.7 3.76 4.49 479.1 19.75 139.9 5.10 6.08 — — — — — — — — — —
60 361.8 12.43 120.3 2.57 3.07 458.7 15.76 136.5 3.55 4.24 — — — — — — — — — —
354-W2 80 321.1 8.27 113.5 1.34 1.60 417.9 10.77 129.7 1.93 2.31 514.7 13.26 145.8 2.54 3.03 — — — — —
CFM 5528 100 280.3 5.78 106.7 .76 .90 377.1 7.77 122.9 1.15 1.38 474.0 9.77 139.0 1.57 1.87 — — — — —
RPM 1100 120 239.6 4.11 99.9 .44 .53 336.4 5.78 116.1 .72 .86 433.2 7.44 132.2 1.02 1.22 — — — — —
HP 1/2 140 198.8 2.93 93.1 .26 .31 295.6 4.35 109.3 .46 .55 392.4 5.78 125.4 .69 .82 489.3 7.20 141.6 .92 1.09
160 158.0 2.04 86.3 .15 .17 254.9 3.28 102.5 .30 .35 351.7 4.53 118.6 .47 .56 448.5 5.78 134.8 .65 .78
180 117.3 1.34 79.6 .08 .09 214.1 2.45 95.7 .19 .22 310.9 3.56 111.8 .32 .38 407.7 4.67 128.0 .47 .56
50 440.0 18.14 125.8 5.00 5.92 559.0 23.05 143.5 7.55 8.97 — — — — — — — — — —
60 417.0 14.33 122.4 3.41 3.95 535.0 18.38 140.0 5.13 6.16 — — — — — — — — — —
400-W2 80 372.0 9.59 115.6 1.78 2.18 489.0 12.60 133.1 2.79 3.26 620.0 15.98 152.7 4.09 4.77 — — — — —
CFM 6017 100 326.0 6.72 108.8 1.08 1.33 443.0 9.13 126.3 1.62 2.03 590.0 11.96 146.7 2.58 3.03 — — — — —
RPM 1140 120 280.0 4.81 101.9 .70 .92 397.0 6.82 119.4 1.10 1.37 540.0 9.28 140.8 1.69 2.04 — — — — —
HP 3/4 140 234.0 3.45 95.0 .51 .71 351.0 5.17 112.5 .78 1.00 501.0 7.38 134.9 1.22 1.53 612.0 9.01 151.5 1.60 2.00
160 188.0 2.42 88.1 .35 .52 305.0 3.93 105.6 .57 .78 461.0 5.94 128.9 .91 1.21 568.0 7.37 144.9 1.20 1.52
180 143.0 1.64 81.4 .23 .43 259.0 2.97 98.7 .42 .62 422.0 4.83 123.1 .71 .92 527.0 6.04 138.8 .96 1.14
