Performance
Data
Table PD-5 (Continued) – Model P-L Unit Heater Hot Water Capacities – 60°F Ent. Air Temp. (Capacities shown are for units with all Air Ports open)
(Conversion Factors in Table SP-11 Apply Only to 200 F Entering Water Temperature Columns)
Entering Water Temperature
Water 260 F 300 F 340 F 380 F
Unit Temp. PD PD PD PD PD PD PD PD
Size Drop °F MBH GPM FT S.W.T. H.W.T. MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T MBH GPM FT S.W.T. H.W.T.
50 302.8 12.48 102.3 .70 .95 387.8 15.98 114.2 1.09 1.46 472.7 19.49 126.0 1.55 2.08 557.6 22.99 137.9 2.07 2.78
60 278.5 9.57 98.9 .43 .58 363.4 12.48 110.7 .69 .92 448.3 15.40 122.6 1.00 1.34 533.3 18.32 134.5 1.35 1.82
384-P-L 80 229.8 5.92 92.1 .18 .24 314.7 8.11 103.9 .31 .42 399.6 10.30 115.8 .47 .63 484.6 12.48 127.7 .66 .89
CFM 6600 100 181.0 3.73 85.3 .08 .10 266.0 5.48 97.1 .15 .20 350.9 7.23 109.0 .24 .33 435.8 8.98 120.9 .36 .48
RPM 1140 120 132.3 2.27 78.5 .03 .04 217.2 3.73 90.3 .07 .10 302.2 5.19 102.2 .13 .18 387.1 6.65 114.1 .21 .28
HP 3/4 140 — — — — — 168.5 2.48 83.5 .03 .05 253.5 3.73 95.4 .07 .10 338.4 4.98 107.3 .12 .16
160 — — — — — — — — — — 204.7 2.64 88.6 .04 .05 289.7 3.73 100.4 .07 .10
180 — — — — — — — — — — — — — — — 240.9 2.76 93.6 .04 .05
200 — — — — — — — — — — — — — — — 192.2 1.98 86.8 .02 .03
50 381.8 15.74 97.5 1.09 1.48 487.0 20.07 107.9 1.66 2.26 592.2 24.41 118.2 2.34 3.19 697.4 28.75 128.5 3.11 4.24
60 353.0 12.12 94.7 .67 .92 458.2 15.74 105.0 1.06 1.44 563.4 19.35 115.4 1.52 2.07 668.6 22.97 125.7 2.05 2.79
500-P-L 80 295.3 7.61 89.0 .29 .39 400.5 10.32 99.3 .49 .66 505.7 13.03 109.7 .73 1.00 610.9 15.74 120.0 1.02 1.39
CFM 9380 100 237.6 4.90 83.3 .13 .17 342.8 7.06 93.7 .24 .33 448.0 9.23 104.0 .39 .53 553.2 11.40 114.4 .56 .76
RPM 1160 120 179.9 3.09 77.7 .06 .07 285.1 4.90 88.0 .12 .17 390.3 6.70 98.4 .22 .29 495.5 8.51 108.7 .33 .45
HP 1-1/2 140 — — — — — 227.4 3.35 82.3 .06 .08 332.6 4.90 92.7 .12 .17 437.8 6.45 103.0 .20 .27
160 — — — — — — — — — — 274.9 3.54 87.0 .07 .09 380.1 4.90 97.4 .12 .16
180 — — — — — — — — — — 217.3 2.49 81.3 .04 .05 322.5 3.69 91.7 .07 .10
200 — — — — — — — — — — — — — — — 264.8 2.73 86.0 .04 .06
50 464.0 19.13 101.5 .95 1.24 591.6 24.39 112.9 1.45 1.89 719.2 29.65 124.4 2.04 2.66 846.9 34.91 135.8 2.71 3.53
60 429.2 14.74 98.4 .59 .77 556.8 19.13 109.8 .92 1.21 684.4 23.51 121.2 1.32 1.73 812.1 27.89 132.7 1.78 2.33
600-P-L 80 359.6 9.26 92.2 .25 .33 487.2 12.55 103.6 .42 .56 614.8 15.84 115.0 .64 .83 742.4 19.13 126.4 .89 1.16
CFM 10,300 100 290.0 5.98 86.0 .11 .15 417.6 8.61 97.4 .21 .28 545.2 11.24 108.8 .34 .44 672.8 13.87 120.2 .49 .64
RPM 1160 120 220.4 3.79 79.7 .05 .06 348.0 5.98 91.1 .11 .14 475.6 8.17 102.6 .19 .25 603.2 10.36 114.0 .29 .37
HP 1-1/2 140 — — — — — 278.4 4.10 84.9 .05 .07 406.0 5.98 96.3 .11 .14 533.6 7.86 107.8 .17 .23
160 — — — — — — — — — — 336.4 4.33 90.1 .06 .08 464.0 5.98 101.5 .10 .14
180 — — — — — — — — — — 266.8 3.06 83.9 .03 .04 394.4 4.52 95.3 .06 .08
200 — — — — — — — — — — — — — — — 324.8 3.35 89.1 .04 .05
50 558.0 23.00 103.2 1.06 1.44 711.7 29.34 115.1 1.62 2.21 865.4 35.67 127.0 2.27 3.12 1019.1 42.01 138.9 3.03 4.16
60 516.0 17.72 100.0 .65 .89 669.6 23.00 111.9 1.03 1.41 823.3 28.28 123.8 1.48 2.03 977.0 33.56 135.7 1.99 2.74
720-P-L 80 431.8 11.12 93.4 .28 .38 585.5 15.08 105.3 .47 .65 739.2 19.04 117.2 .71 .97 892.9 23.00 129.2 .99 1.36
CFM 11,900 100 347.6 7.17 86.9 .12 .17 501.3 10.33 98.8 .24 .32 655.0 13.50 110.7 .38 .52 808.7 16.67 122.6 .55 .75
RPM 1165 120 263.5 4.53 80.4 .05 .07 417.2 7.17 92.3 .12 .16 570.9 9.80 104.2 .21 .29 724.5 12.44 116.1 .32 .43
HP 3 140 — — — — —- 333.0 4.90 85.8 .06 .08 486.7 7.17 97.7 .12 .16 640.4 9.43 109.6 .19 .26
160 — — — — — — — — — — 402.5 5.19 91.2 .07 .09 556.2 7.17 103.1 .12 .16
180 — — — — — — — — — — 318.4 3.65 84.7 .03 .05 472.1 5.41 96.6 .07 .09
200 — — — — — — — — — — — — — — — 387.9 4.00 90.0 .04 .05
