UH-PRC001-EN

18

Selection
Procedure

Motor and Fan Speeds
Motor and fan speeds are selected to
provide efficient performance. The
solid-state speed control will provide an
infinite number of speeds between the
highest and the lowest cataloged fan
speeds. The speed control is not
calibrated in specific fan speeds. For use
on units with 115 volt/60 cycle/
1 phase, 1/8 hp and smaller standard
motors only.

Standard and Bypass Units
Standard models meet most
requirements and are most economical.
Bypass units meet conditions as
mentioned above, and are also used
where low final temperature is specified.

25 and 50 Cycle Unit Heat Capacities
Table SP-8 shows the Btu, cfm, and the
hp required on unit heaters when
operated on 25 or 50 cycle circuits.
The multipliers in Table SP-8 may be
applied to standard 60 cycle unit
capacities to determine the capacities of
the same unit when operating on
25 or 50 cycle current. These multipliers
may be used on units cataloged at
1050 to 1150 RPM.
For the smaller Trane Unit Heaters
cataloged at 1550 RPM, the capacity data
in the catalog may be applied to either
25 or 50 cycle service.

Table SP-7 – Factors For Determining Steam Capacity Of Model P Projection Unit Heaters At Various Pressures And Temperatures

Table Based on 2 PSIG and 60 F Entering Air

Steam

Temperature of Entering Air (F)

Pressure PSIG

-10

0

10

20

30

40

50

60

70

80

90

100

0

1.49

1.41

1.33

1.25

1.18

1.11

1.03

0.96

0.90

0.83

0.76

0.69

2

1.52

1.45

1.37

1.29

1.22

1.15

1.07

1.00

0.93

0.86

0.80

0.73

5

1.58

1. 50

1.42

1.34

1.27

1.20

1.12

1.05

0.98

0.91

0.85

0.78

10

1.64

1.57

1.49

1.41

1.34

1.27

1.19

1.12

1.05

0.98

0.91

0.85

Draw-

15

1.70

1.62

1.55

1.47

1.40

1.32

1.25

1.18

1.11

1.04

0.97

0.90

Through

20

1.75

1.67

1.60

1.52

1.45

1.37

1.30

1.23

1.16

1.09

1.02

0.96

Unit

30

1.83

1.75

1.68

1.61

1.53

1.46

1.39

1.32

1.25

1.18

1.11

1.04

40

1.90

1.82

1.75

1.68

1.61

1.53

1.46

1.39

1.32

1.25

1.18

1.11

50

1.96

1.87

1.81

1.74

1.67

1.59

1.52

1.45

1.38

1.31

1.24

1.17

60

2.02

1.94

1.87

1.79

1.72

1.64

1.57

1.50

1.43

1.36

1.29

1.22

70

2.07

1.99

1.92

1.84

1.76

1.69

1.62

1.55

1.47

1.40

1.33

1.27

75

2.10

2.02

1.94

1.86

1.79

1.71

1.64

1.57

1.49

1.42

1.36

1.29

Note:
To determine the Btu per hour capacity of a Model P projection unit heater at any steam pressure and entering air temperature, multiply rated capacity at 2 psig steam 60 F entering air (Table
SP-5) by factor from above table.

Model P Nomenclature

UHP A 0 4 2 P 4 C A A 1 T A R C A D B E

123

4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21

Digits 1,2,3 – Product Type

Digit 4 – Development Sequence

Digits 5,6,7 – Unit Size

Digit 8 – Coil Type

Digit 9 – Fin Series

Additional Selection Data

Digit 10 – Design Sequence

Digit 11 – Tube Material

Digit 12 – Fin Material

Digit 13 – Voltage

Digit 14 – Motor Type

Table SP-8 – Factors for Determining Unit
Heater Capacities at 25 or 50 Cycles

Multiplier To Be Applied To

RPM

60-Cycle 1100 RPM Ratings

25 CY

50 CY

BTU

CFM

HP

1425

1425

1.17

1.25

1.95

950

.87

.833

.572

710

710

.7

.623

.242

Table SP-9 – Properties of Steam

Gauge Pressure

Temp.

Latent

Lbs.

F

Heat

2

219

965

5

227

960

10

239

952

15

250

945

20

259

939

25

267

933

30

274

928

40

287

919

50

298

911

60

307

904

70

316

897

75

320

891

Digit 15 – Fan Guard

Digit 16 – Unit Coating

Digit 17 – Diffuser

Digit 18 – Manual Starter

Digit 19 – Speed Controller (115/60/1
standard motors)

Digit 20 – Thermostats

Digit 21 – Subbase
