6. Operation in Parameter Setup Mode

6-1

In this mode, you can set basic parameters and extended parameters.
This mode also allows you to use the history function (inverter’s parameter ) and
the changed parameter search function (inverter’s parameter ) easily by simply
selecting the desired function from a menu.

Functions of function keys
: Brings you to the Top View Mode.
: Brings you to the Status Monitor Mode.

When Quick mode is selected
The window shown in the figure at right appears
when Quick mode is selected using the EASY key
function.
This window displays the parameter currently
selected for Quick mode.

Functions of function keys
: Brings you to the Top View Mode.
: Displays the previous window.
: Displays the next window.
: Brings you to the Status Monitor Mode.

6.1 Searching for the change histories of parameters

(History function)

The change histories of up to 5 parameters can also be displayed in a list form in order
of novelty.

Select/confirm “History function” using the
control dial.
Change histories are displayed in a list form in
order of novelty.
If the number of change histories exceed 5,
change histories except the 5 latest ones are
deleted in the order in which changes were made.

Functions of function keys
: Brings you to the Top View Mode.

In this window, settings can be changed.

Pressing the control dial displays the Parameter Setting window, in which you can
change settings as required.
⇒ For the steps to be followed, see the following pages.

Parameter Setup Mode

History function

Top

:Base frequency 1

CMOd :Command input mode
----

:There is no history

----

:There is no history

----

:There is no history

Parameter Setup Mode

Category Selection

Top

Mon

History function

Basic Parameters
Extended Parameters
Changed Parameters

Parameter Setup Mode

Mon

Quick mode

Top

AU4 :Automatic

function

set

:V/f control mode

FH :Maximum

frequency

ACC

:Acceleration time 1

DEC

:Deceleration time 1
