5. Operation in Top View Mode
5-5
5.4 Performing jog run
When Panel Jog Run is selected (parameter F262=1, CMOd=1), “JOG” is displayed in
the lower right corner of the window. When “JOG” is displayed, jog run can be
performed using the [F4] key.
The switching to jog run cannot be performed during operation. When switching to Jog
Run mode, operation has to be stopped temporarily.
1
Press the [F4] key to carry out jog run.
The jog run frequency is displayed on the screen.
(In this example, the operation frequency is set at
5.0Hz.)
Operation continues as long as the [F4] key is
pressed, and it stops when the [F4] key is
released.
Functions of function keys
: Switches between Quick mode and Standard
Setting mode.
: Brings you to the Language selection window.
: Executes a jog run command.
Top View Mode
FWD 60.0 Hz JOG
5.0
Hz
Lng Quick JOG
F1
F2
F4
F1 F2 F4
Top View Mode
FWD 60.0 Hz STOP
0.0
Hz
Lng Quick JOG
