5. Operation in Top View Mode
5-6
5.5 Emergency stop/reset operation
To make an emergency stop or to reset the inverter, follow these steps. An emergency
stop can be made when operation is performed with the terminal board (parameter
CMOd=0, 2, 3 or 4).
1
Press the [STOP/RESET] key, which displays
the blinking code “EOFF” in the upper right
corner of the window.
2
Then press the [STOP/RESET] key again.
The Emergency Stop window appears and the
blinking code “E” is displayed.
3
Then press the [STOP/RESET] key again.
The Trip window appears and the blinking code
“CLr” is displayed in it.
4
Last of all, press the [STOP/RESET] key once
again to reset the inverter.
Top View Mode EOFF
FWD 60.0 Hz RUN
60.0
Hz
Emergency stop?
Lng Quick ---
Top View Mode
FWD 60.0 Hz Trip
E
Emergency stop
Lng Quick ---
Top View Mode
FWD 60.0 Hz Trip
CLr
Trip reset? (STOP-Key)
Lng Quick ---
