5. Operation in Top View Mode
5-1
When the remote keypad is turned on, it enters this mode first, which allows you to
monitor the operating status, set an operation frequency, use a function key as the
EASY key, and switch between languages.
When Panel Jog Run is selected, a jog run frequency also can be specified in this
mode.
„
Explanation of the top window
• Display of commands executed:
“FWD” or “REV” is displayed to indicate the
direction of rotation.
The operation frequency is displayed in the form
of “††

† Hz.”
• Display of operating status:
“RUN” is displayed during operation.
“STOP” is displayed during a stop.
“Trip” is displayed in the event of tripping.
• Display of output frequency:
The operation frequency is displayed in the form of
“††.
† Hz.”
• Display of alarm/tripping:
If an error or tripping occurs, an error or trip code is displayed.
• Display of error/tripping message:
If an error or tripping occurs, an error or trip message is displayed.
Functions of function keys
: Switches between Quick mode and Standard Setting mode.
: Brings you to the Language selection window.
5.1 Setting a panel operation frequency
When Frequency input mode1 (parameter FMOd=4) as a frequency setting mode, an
operation frequency can be set with the remote keypad.
1
Press the control dial.
The panel frequency window appears.
The current operation frequency setting is displayed
at the center of the window.
The current output frequency is displayed in the
upper right section of the window.
The minimum allowable frequency (min) and the
maximum allowable frequency (max) are displayed
at the bottom of the window.
Functions of function keys
The functions keys allow you to select the position or decimal place of each figure
(operation frequency) you want to increment or decrement with the control dial.
: Selects the position of hundreds.
: Selects the position of tens.
: Selects the position of ones.
: Selects the first decimal place.
Basic Parameters
FC
Ч100 Ч1000 Ч10 Ч1
Output frequency
0.0
Hz
0.0Hz
min=0.0 max=60.0
Panel frequency
Top View Mode
FWD 60.0 Hz RUN
60.0
Hz
Overheat alarm
Lng Quick ---
Display of commands
executed Display of
operating status
Display of output frequency
Display of alarm/tripping
Display of
error/tripping
message
5. Operation in Top View Mode
F1 F2 F3 F4
F1
F2
F3
F4
F1
F2
F1 F2
