83-507-5002 Rev. B
62
Print Power On
Time
Byte 1
1010 0110
Byte 2
xxxx xxxx
Power On
time in min-
utes
Read the time the supply is active
under AC Power. xxxx xxxx is the
address of the supply in binary.
Returns a 32 Bit integer as 8 Hex
bytes. A ‘$’ sign is appended to
the data followed by a 2 byte
check-sum. A total of 11 bytes are
returned.
Retransmit last
message
110x xxxx Last message Retransmit last response from a
command. x xxxx is the address of
the supply in binary.
Acknowledge
SRQ
111x xxxx None Acknowledge SRQ. If retransmis-
sion of SRQ is enabled, it will re-
main enabled for the next SRQ. X
xxxx is the address of the supply
in binary.
Test if MD Mode
is Installed
Byte 1
1010 1010
Byte 2
xxxx xxxx
0 or 1
Returns a 0 if not installed or a 1 if
installed. A ‘$’ sign followed by a 2
bytes checksum and Carriage Re-
turn is appended to the data. xxxx
xxxx is the address of the supply
in binary.
Supply Initiated
Communications
SRQ 100x xxxx N/A SRQ from supply when in MD
Mode. X xxxx is the address of the
supply in binary.
Table 7-4. SINGLE BYTE COMMUNICATIONS
GEN750W models
Table 7-5: Current programming range
Model Minimum
(A)
Maximum
(A)
GEN6-100 000.00 100.00
GEN8-90 00.00 90.00
GEN12.5-60 00.000 60.000
GEN20-38 00.000 38.000
GEN30-25 00.000 25.000
GEN40-19 00.000 19.000
GEN60-12.5 00.000 12.500
GEN80-9.5 0.000 9.500
GEN100-7.5 0.000 7.500
GEN150-5 0.000 5.000
GEN300-2.5 0.000 2.500
GEN600-1.3 0.000 1.300
NOTE:
The power supply can accept values 5% higher than the table values, however it is not
recommended to program the power supply over the rated values.
