Specifications
(TX-SR600/600E)
AMPLIFIER SECTION
Continuous average power output (FTC)
All channels:
80 W per channel min. RMS at 8
Ω, 2
channels driven from 20 Hz to 20
kHz with no more than 0.08% total
harmonic distortion.
105 W min. RMS at 6
Ω, 2 channels
driven from 1 kHz with no more
than 0.1% total harmonic distortion.
Continuous power output (DIN)
115 W at 6
Ω
Maximum power output (EIAJ)
145 W at 6
Ω
Dynamic power output (stereo)
2
× 215 W at 3 Ω
2
× 160 W at 4 Ω
2
× 95 W at 8 Ω
Total harmonic distortion:
0.08% at rated power
0.08% at 1 W output
IM distortion:
0.08% at rated power
0.08% at 1 W output
Damping factor:
60 at 8
Ω
Input sensitivity and impedance
LINE (CD, TAPE, DVD,
VIDEO 1-4):
200 mV, 47 k
Ω
MULTICHANNEL INPUT
(FRONT L/C/R, SURROUND
L/R):
200 mV, 47 k
Ω
(SUBWOOFER):
36 mV, 47 k
Ω
COAXIAL (DIGITAL):
0.5 Vp-p, 75
Ω
DVD, VIDEO 1, 2, 3, 4:
1 Vp-p, 75
Ω
1 Vp-p, 75
Ω (Y)
0.28 Vp-p, 75
Ω (C)
COMPONENT VIDEO 1, 2:
1 Vp-p, 75
Ω (Y)
0.7 Vp-p, 75
Ω (P
B
, P
R
)
Output level and impedance
Rec out (TAPE, VIDEO 1):
200 mV, 470
Ω
Pre out:
1 V, 470
Ω
VIDEO (VIDEO 1,
MONITOR OUT):
1 Vp-p, 75
Ω
1 Vp-p, 75
Ω (Y)
0.28 p-p, 75
Ω (C)
COMPONENT VIDEO OUT:
1 Vp-p, 75
Ω (Y)
0.7 Vp-p, 75
Ω (P
B
, P
R
)
Frequency response:
10 Hz to 100 kHz : +1/–3 dB
(CD in Direct mode)
Tone control
Bass:
±12 dB at 50 Hz
Treble:
±12 dB at 20,000 Hz
Signal-to-noise ratio (stereo)
CD/Tape:
100 dB (IHF A, 0.5 V input)
Muting:
–50 dB
TUNER SECTION
FM
Tuning range:
87.5–108.0 MHz (50-kHz steps)
Usable sensitivity
Mono:
11.2 dBf, 1.0 µV (75
Ω IHF)
0.9 µV (75
Ω DIN)
Stereo:
17.2 dBf, 2.0 µV (75
Ω IHF)
23 µV (75
Ω DIN)
50 dB quieting sensitivity
Mono:
17.2 dBf, 2.0 µV (75
Ω)
Stereo:
37.2 dBf, 20 µV (75
Ω)
Capture ratio:
2.0 dB
Image rejection ratio
USA & Canadian models:
40 dB
Other area models:
85 dB
IF rejection ratio:
90 dB
Signal-to-noise ratio
Mono:
76 dB
Stereo:
70 dB
Alternate channel attenuation:
55 dB
Selectivity:
50 dB (DIN)
AM suppression ratio:
50 dB
Total harmonic distortion
Mono:
0.2%
Stereo:
0.3%
Frequency response:
30 Hz–15 kHz, ±1.0 dB
Stereo separation:
45 dB at 1 kHz
30 dB at 100 Hz–10 kHz
AM
Tuning range
USA & Canadian models:
530 to 1,710 kHz (10-kHz steps)
European & Australian models: 522 to 1,611 kHz (9-kHz steps)
Worldwide models:
531 to 1,602 kHz (9-kHz steps)
530 to 1,710 kHz (10-kHz steps)
Usable sensitivity:
30 µV
Image rejection ratio:
40 dB
IF rejection ratio:
40 dB
Signal-to-noise ratio:
40 dB
Total harmonic distortion:
0.7%
GENERAL
Power supply
USA & Canadian models:
AC 120 V, 60 Hz
European & Australian models: AC 230–240 V, 50 Hz
Some Asian models:
AC 220–230 V, 50/60 Hz
Worldwide models:
AC 220–230 and 120 V switchable,
50/60 Hz
Power consumption
USA & Canadian models:
5.5 A
Other models:
450 W
Dimensions (W
× H × D):
435
Ч 175 Ч 431.5 mm
17-1/8"
Ч 6-7/8" Ч 16-15/16"
Weight
USA & Canadian models:
24.5 lbs.
Other models:
12.1 kg
REMOTE CONTROLLER
Transmitter:
Infrared
Signal range:
Approx. 16 ft., 5 meters
Power supply:
Two “AA” batteries (1.5 V
× 2)
Specifications and features are subject to change without notice.
