Advanced Setup—Continued
Speaker Level Calibration
Here you can adjust the level of each speaker with the
built-in test tone so that the volume of each speaker is the
same at the listening position.
Note:
The speakers cannot be calibrated while the output of the
AV receiver/AV amplifier is muted or while a pair of
headphones is connected.
Notes:
• This procedure can also be performed by using the
remote controller. First press the [TEST TONE] but-
ton to output the test tone. Use the [LEVEL–] and
[LEVEL+] buttons to set the volume, and use the [CH
SEL] button to select the speakers.
• This procedure can also be performed on the AV
receiver/AV amplifier by using its [SETUP] button,
arrow buttons, and [ENTER] button.
1 Press the [RECEIVER] button fol-
lowed by the [SETUP] button.
The main menu appears onscreen.
2 Use the Up and Down [ ]/[ ]
buttons to select “2. Speaker
Setup,” and then press [ENTER].
The Speaker Setup menu appears.
This setting is set automatically by the Automatic
Speaker Setup function (see page 41).
1, 6
2-5
2, 3
1
2. Speaker Setup
1. Speaker Settings
2. Speaker Config
3. Speaker Distance
4. Level Calibration
5. Equalizer Settings
3 Use the Up and Down [ ]/[ ]
buttons to select “4. Level Cali-
bration,” and then press
[ENTER].
The Level Calibration menu appears
and the pink noise test tone is output by
the front left speaker.
Note:
Speakers that you set to No or None on
the Speaker Configuration page
(page 70) cannot be selected.
4 Use the Up and Down [ ]/[ ]
buttons to select each speaker,
and use the Left and Right [
]/
[ ] buttons to set the volume.
The volume can be adjusted from –12
to +12 dB (–15 dB to +12 dB for the
subwoofer) in 1 dB steps.
5 Repeat step 4 until the volume of
the test tone from each speaker
is the same.
6 Press the [SETUP] button.
The setup menu closes.
2–4. Level Calibration
Left 0dB
Center 0dB
Right 0dB
Surr Right
0dB
Surr Back R 0dB
Surr Back L 0dB
Surr Left 0dB
Subwoofer 0dB
