Connecting the AV Receiver/AV Amplifier—Continued
• With connection
, you can listen to and record audio from your TV and listen in Zone 2.
• To enjoy Dolby Digital and DTS, use connection
or
. (For recording, use
and
, or
and
.)
If your TV has no audio outputs, connect an audio output from your VCR or cable or satellite receiver
to the AV receiver/AV amplifier and use its tuner to listen to TV programs through the AV receiver/AV
amplifier (see pages 29 and 31).
Connecting Your TV or Projector
Connection
AV receiver/AV amplifier
Signal flow
TV
Picture quality
COMPONENT VIDEO OUT
Component video input
Best
MONITOR OUT S
S-Video input
Better
MONITOR OUT V
Composite video input
Standard
GAME/TV IN L/R
Analog audio L/R output
DIGITAL COAXIAL IN 2 (CBL/SAT)
Digital coaxial output
DIGITAL OPTICAL IN 1 (GAME/TV)
Digital optical output
Step 1: Video Connection
Choose a video connection that matches your TV (
,
, or
), and then make the connection.
A B
C
Step 2: Audio Connection
Choose an audio connection that matches your TV (
,
, or
), and then make the connection.
a
b
c
a
b
c
a
b
a
c
A
B
C
a
b
c
Y
COAXIAL
OUT
P
B
COMPONENT VIDEO IN
P
R
S VIDEO
IN
AUDIO
OUT
VIDEO
IN
L
R
OPTICAL
OUT
b
c
A
B
C
B
a
C
TV, projector,
etc.
Connect one or the other
Connection
must be assigned (see page 50)
b
Hint!
