Starting DPA for port 1

Authentication successful.

Escape Sequence is: Control-]

You are now master for the port.

Enabling unauthorizedportaccess to a set of ports assigned to 'Anonymous' group.

Unauthorized port access is only available for configured DPA methods. Use the following
command:

admin > Security > LoginSettings > unauthorizedportaccess enable true

When unauthorizedportaccess is enabled it automatically Enables Anonymous group and the user
is able to configure it according to his requirement:

admin > Security > LoginSettings > unauthorizedportaccess

Unauthorized Port Access Settings:

Enable: 1

Group Settings:

Name: Anonymous

Class: Observer

Ports:

To configure Anonymous group settings go to config > user menu and execute the
following command:
admin > Config > User > editgroup name Anonymous class op ports
1,2,3,4,5

Editing group...

Group Anonymous: Configuration Saved


The 'Anonymous' group is successfully configured.

DPA Anonymous access:
The DPA is already configured. (See the DPA configuration settings section.)
DPA Mode is IP, IP 10.0.13.240 is assigned to port 1.

When accessing the serial port with Anonymous port access, the user name should be
“Anonymous” and empty password as is shown below (The Anonymous access is
granted if both fields username and password are empty ):

ssh –l Anonymous 10.0.13.240

Password:

Authentication successful.

Starting DPA for port 1
