Chapter 4 Configuration Installation and Operation Manual
4-40 Additional Tasks ASMi-52 Ver. 2.5
Figure 4-44. Main Menu (ConfiguRAD Session)
Displaying the ASMi-52 Inventory
The ASMi-52 inventory displays information on the functional blocks of the local
or remote modem.
ASMi-52 consists of the following components:
• SHDSL unit
• DTE unit
• Terminal control port
• 10/100BaseT port
• Alarm relay port
• Power supply.
To display the ASMi-52 inventory:
1. From the Main menu, select Inventory.
The Inventory screen appears (see Figure 4-45 ).
2. Use the following keys to move around the indices.
L – move left, l – scroll left,
R – move right, r – scroll right
U – move up, u – scroll up
D – move down, d – scroll down
– select next changeable cell.
ASMi-52
Main menu
ConfiguRAD
utilities
