Installation and Operation Manual Chapter 6 Troubleshooting and Diagnostics
ASMi-52 Ver. 2.5 Handling Alarms 6-9
Displaying All Alarms
ASMi-52 allows you to display all alarms, irrespective of their origin (system or
port).
To display all alarms:
1. From the Main menu, select Monitoring.
The Monitoring menu appears (see Figure 6-11 ).
2. From the Monitoring menu, select Total Alarms.
The Total Alarms Screen appears (see Figure 6-12 ).
The display of the alarms screen includes the source of alarm (local or remote
device), name of the alarm, its number, severity (major or minor) and status
(always ON), see
Figure 6-12 .
Once the event that caused the alarm is cleared, the ALM indicator turns off.
3. Press to refresh the display.
ASMi-52
Monitoring
1. Total alarms <[]
2. System monitoring <
3. Physical ports status <
4. Physical ports statistics >
5. Open virtual connection
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 6-11. Monitoring Menu
ASMi-52
Total alarms
Source Name Num Severity Status
Remote 1 PSD NOT CONNECTED 8 MAJOR ON
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 6-12. Total Alarms Screen
