Installation and Operation Manual Chapter 4 Configuration
ASMi-52 Ver. 2.5 Configuring ASMi-52 System Parameters 4-13
ASMi-52
Configuration >
1. System configuration >
2. LAN configuration >
3. SHDSL configuration
4. E1 configuration
5. T1 configuration
6. DTE configuration
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 4-16. Configuration Menu
The ASMi-52 management software allows you to perform the following:
• Configuring master clock
• Selecting a local/remote card mode
• Configuring the local/remote card
• Enabling or disabling low speed operation
• Defining management parameters (IP parameters, system information, etc.)
• Defining control port parameters
• Resetting ASMi-52 defaults
• Performing the overall reset of the device or resetting its SHDSL interface.
To display the System Configuration menu:
• From the Configuration menu, select System Configuration.
The System Configuration menu appears (see Figure 4-17 ).
ASMi-52
System Configuration >
1. Master clock
>(Internal)
2. Local Card Mode
3. Remote Card Mode
4. Low Speed Operation
(Enable/Disable)
5. Management >
6. Control port >
7. Factory default >
8. Reset >
9. Save
>
ESC-prev.menu; !-main menu; &-exit; @-scroll
Figure 4-17. System Configuration Menu
