Chapter 4 Configuration Installation and Operation Manual
4-22 Configuring the Physical Ports ASMi-52 Ver. 2.5
4.3 Configuring the Physical Ports
Configuring the SHDSL Interface
The ASMi-52 configuration software allows you to change the modem’s
transmission mode (Annex A or Annex B).
Examples given below illustrate the local device configuration procedures.
To change the transmission mode:
1. From the SHDSL Local Port menu, select Transmission Mode (Main menu >
Configuration > SHDSL Configuration > SHDSL Local Port > Transmission
Mode) to choose a transmission mode: Annex A or Annex B for the SHDSL
Local Port.
The display is refreshed and a new value appears.
2. Select Save to save the changes.
• ASMi-52 units operating in the receive clock mode automatically detect the
standard compatibility value of the central units and configure themselves
accordingly.
ASMi-52
SHDSL local port configuration
1. Power backoff
(Enable)
2. Asym PSD (Symmetric)
3. Line prob (Fixed rate)
4. Configured Wire (2W/4W)
5. Loop attenuation threshold (dB)[0 – 127] (0)
6. SNR margin threshold (dB)[0 – 15]
(0)
7. Transmission mode (Annex_A)
8. Save
>
ESC-prev. menu; !-main menu; &-exit; @-scroll
Figure 4-27. SHDSL Local Port Menu
Note
