Installation guidelines 181, Fully integrated hsb, System – Raymarine Pathfinder User Manual
Page 96
Installation Guidelines
181
Fully integrated hsb
2
system
12/24V Supply
12/24V Supply
12/24V Supply
hsb2
hsb2
SeaTalk
Fluxgate
Compass
SeaTalk
Optional 10 Hz NMEA
fast heading to PC
using E86001 cable
to Serial Port 2
SeaTalk
GPS
Typical SeaTalk System
Scanner
SeaTalk
SeaTalk
SeaTalk
Course Computer (G series)
Distribution Panel
E86001
9 pin cable
E85004
SeaTalk
Interface
E86019
hsb - PC
Interface
2
Serial
Port 1
PCMCIA
Interface
In-line
terminator
Serial
Port 2
10 Hz NMEA
10 Hz NMEA
D8412_1
182
RayTech RNS V6.0 - Users Guide
