SECTION 10: O
PTIONAL
H
EATER
A
CCESSORIES
45 of 75
10.4 Protective Grille Installation
Step 10.4.1 Silicone Cap Installation
Step 10.4.2 Grille End Cap Installation
Step 10.4.3 Grille Installation
Silicone Cap
Grille
Finger
Description
Part Number
Grille Section
08050001
Grille End Cap
08050002
Silicone Cap
91915951-6P
Bend up 90°.
Pull outward.
Grille
Grille End Cap
A
B
C
D
Grille
Grille
End Cap
Reflector
Final Grille
Section
1010 mm
