10.1 Reflector Side Extension Installation
Step 10.1.1 Bracket Installation
Step 10.1.2 Side Reflector Installation
Reflector Side
Extension Bracket
(2 per reflector)
Use additional supports
in high air movement
applications.
Tube and Reflector Hanger
Reflector
Tube
Reflector Support
Description
Part Number
Reflector Side Extension Package
S7377K
Reflector Side Extension
01368000
Retainer Clips
02751200
Reflector Side Extension
01329910
Sheet Metal Screw
Sheet Metal Screw
