Page 18
B
LACKHEAT
®
I
NSTALLATION
O
PERATION
AND
S
ERVICE
M
ANUAL
12 of 74
Figure 18: Critical Hanger Placement
* Allows for thermal expansion of system.
Hanger
Side View
Front View
Hanger
Bow Shackle
I-Beam
I-Beam
Beam
Clamp
Bow
Shackle
Anchor
Concrete
Beam
Locknut
Washer
Screw Hook
min. 10 mm
Washer
Wood
Beam
Turnbuckle
(not included)
600 mm
minimum*
300 mm
minimum*
10 mm
Rod
Typical Suspension Details
45° Angle
100 mm
Max.
Description
Part Number
Burner Tube
03051100
Bow Shackle
E0007576
Tube/Reflector Hanger
03090100
