Renesas Emulation Pod forM16C/20 Series M30200T-RPD-E User Manual

Page 21

background image

( 19 / 32 )

Figure 4.3 Circuit of oscillator board OSC-2

Figure 4.3 shows the OSC-2 circuit. Use the circuit constants recommended by the
manufacturer of the oscillator.

* X1: 5.08-mm-pitch 2-pin oscillator

IC1: Inverter (Unbuffer)

*

X2: 2.54-mm-pitch 2-pin oscillator

*

X3: 2.54-mm-pitch 3-pin oscillator

IC 1

R 1

C2

C 1

X 1 ,X 2

C LK

V cc

G N D

R 2

J1-3

10

11

8

9

2

1

4

3

6

5

12

13

C 3

IC 1

J1-1

J1-2

J1-4

G N D

IC 1

*

*

X 3

*

IC 1

14

7
