Notes on the Target System:
• Because the emulation pod main unit does not have the capacity to supply power to other devices,
design your system so that the emulator MCU is powered by the target system.
• Make sure that the target's supply voltage is 2.7 to 5 V.
• Before turning on power to anything, check the host machine, emulator main unit, emulation pod
main unit, pod probe, converter board and user's target system are properly connected. As
explained here following, activate power to units as simultaneously as possible. Reverse the
procedure to turn them off.
(1) Turn on the target system.
(2) Turn on the emulator main unit.
IMPORTANT
Notes on PC4701 Emulator Main Units:
• EMI standards are not met when this product is used with the PC4700H or PC4700L emulator main
unit.
• The PC4700H emulator main units whose serial number ends with a number cannot be used with
M30200T-RPD-E. Use only products whose serial number ends with a letter of the alphabet. The
serial number is on the bottom of the PC4700H.
Example: 5KE100 .......... Can NOT be used with M30200T-RPD-E. Requires an upgrade.
Example: 5LE123B ........ Can be used with M30200T-RPD-E.
• Do not turn off the power when downloading firmware. If the emulator is powered off in the middle
of the process, it will become unable to start up normally. In cases when the power is inadvertently
shut off, re-execute downloading.
Note on Abnormal Operation of PC4701 System:
• If the PC4701 system does not pass all self-checks (excluding when an target system error occurs),
there is the possibility of trouble in the system. In such case, contact the place of purchase. (Self-
check should be executed when the target system is not connected.)
• If the emulator main unit malfunctions due to external interference or some other causes, follow
the steps given below.
(1) Press the system reset switch located on the front panel of the emulator main unit.
(2) If the emulator does not return to the normal operation despite the step (1) above, turn off the
power source of the emulator main unit, turn it on again.
