Setting Up the Printer
60
2
Buttons and Indicators on the Network Interface Board
1. Indicator (green)
Stays on while the printer is in a network
environment.
2.
Indicator (green)
Stays on while 100BASE-TX is working.
Stays off while 10BASE-T is working.
3. Indicator (orange)
Stays on while the network interface
board is working.
4. Button
Hold down this button for more than two
seconds to print the network configura-
tion page. Hold down this button for
more than five seconds to print system
log information.
Note
❒ You can print the network configura-
tion page and system log information
using the “Network Status” and “Net-
work Log” menu under the “List
Print” menu on the operation panel.
For more information, see P.54 “Print-
ing a Configuration Page”.
ZAEX010E
1
3
2
4
