Ricoh Aficio AP3200 User Manual
Page 75
Connecting the Printer
59
2
D
Attach the ferrite core to the loops.
A: 10 cm (4 inch)
E
Attach the network cable to the 10BASE-T/100BASE-TX port of the printer.
Reference
See P.5 “Exterior: Front View” to confirm the position of the 10BASE-T/
100BASE-TX port.
F
Connect the other end of the cable to the network.
ZAEH250E
