Setting Up the Printer
44
2
D
Release the green lever and slide
the toner holder out until it stops
gently.
Important
❒ If you continue to push the
green lever to slide the toner
holder, the toner holder might
drop.
E
Move the new toner bottle back
and forth about five or six times
(
A A A A), and remove the black cap of
the new toner bottle by turning it
counterclockwise (
B B B B).
Important
❒ Do not remove the inside cap.
Note
❒ After removing the black cap
from the bottle, toner can scatter
easily. Do not shake or jar the
bottle.
F
Put the toner bottle on the printer
side of the toner holder (
A A A A), then
push its head downwards to lock
it in place (
B B B B).
G
Slide the toner holder into the
printer until it clicks into place,
and push the green handle down.
H
Close the front cover.
ZAET030E
ZAET040E
ZAET022E
