Installing Options
27
2
N
Close the right cover by pushing
the area as shown in the illustra-
tion.
O
If the mailbox is not installed, at-
tach the interchange unit cover that
was removed in step
IIII. Attach the
side of the cover facing the front of
the printer first (
A A A A) and then the
other side of the cover (
B B B B).
Note
❒ If you are going to install the
mailbox, skip this step.
P
Attach the connector of the inter-
change unit to the socket on the
back of the printer as shown in
the illustration.
Installing AD380 (Duplex Unit)
Preparation
The installation procedure when
the bypass tray unit is not yet in-
stalled is described below.
If the bypass tray unit is already in-
stalled, perform steps
I to J of P.31
“Installing Bypass Tray Type 270”.
You can skip steps
E to H below.
Important
❒ If you install the duplex unit, the
interchange unit must be installed
first.
A
Confirm that the box contains the
following items.
1. Holder
2. Cover of the holder
3. Socket screws (3 pcs)
4. Wrench
5. Hook
6.
Hook holder
• Installation Guide
ZAEP170E
ZAEP180E
ZDEP070E
1
2
3
4
5
6
ZAEP382E
