Installing Options
23
2
E
By holding the handles, align the
front face of the printer and the
paper feed unit, then place the
printer on the paper feed unit.
Important
❒ The printer should be held by at
least two people.
❒ Do not pinch the harness on the
back of the paper feed unit and
the printer.
F
Return the handles that were
pulled out in step
DDDD to their origi-
nal position.
G
Slide tray 2 out until it stops. Af-
ter that, lift the front, and pull it
out.
H
Use a coin to fasten the two
screws that join the paper feed
unit and the printer.
I
Return tray 2.
J
Attach the two securing brackets
on the back of the printer and the
paper feed unit, and fasten their
screws using a coin.
K
Remove the adhesive tape hold-
ing the cable and connect the har-
ness on the back of the printer.
ZAEP600E
ZAEP050E
ZAEP060E
ZAEP070E
ZAEP080E
ZAEP082E
