Chapter 6. Troubleshooting
6.1 Flowchart to Remedy Troubles
Figure 6.1 shows the Flowchart to Remedy Troubles from when power to the emulator is activated
until emulator debugger M3T-PD38 starts up.
Figure 6.1 Troubleshooting when starting up the emulator system
Not normal/Error displayed
Normal
Not normal/Error displayed
Normal
Not normal/Error displayed
Normal
Emulator system has started up normally
Check the front panel
LED of the PC4701
Init dialog box of the M3T-
PD38 displayed
Program Window of the M3T-
PD38 displayed
Starting up the emulator
(Turn ON the power of emulator and target
system simultaneously)
See, "6.1 (1) When the LED Display of the PC4701 is Abnormal"
(page 59).
Starting up M3T-PD38 (part 1)
Double-click on the M3T-PD38 icon to start up
M3T-PD38
See, "6.1 (2) When the Init Dialog Box is Not Displayed" (page
59).
Starting up M3T-PD38 (part 2)
Close the Init dialog box (click OK button)
Troubleshooting until the emulator system starts up
See "6.1 (3) When the Program Window is Not Displayed
(Target System Not Connected) " (page 60) and "6.1 (4) When
the Program Window is Not Displayed (Target System
Connected)" (page 61).
