2.2 Package Components
The M37641T2-RPD-E package consists of the following items. When unpacking, check to see if
your M37641T2-RPD-E package contains all the items listed below.
Package components
Please keep the M37641T2-RPD-E's packing box and cushion material in your place for reuse at a
later time when sending your product for repair or other purposes. Always use these packing box and
cushion material when transporting the M37641T2-RPD-E.
If any of these items are missing or found faulty, please contact your local distributor. Also, if there
is any question or doubt about the packaged product, contact your local distributor.
2.3 Other Tool Products Required for Development
To bring forward programs development on the 7641 and 7643 Group MCUs, the products listed
below are necessary in addition to those contained package above. Get them separately.
Other tool products
* To purchase these products, contact your nearest distributer.
* The IC61-080-081 is a product of Yamaichi Electronics Co., Ltd. For purchasing it or for
technical information, contact Yamaichi Electronics Co., Ltd. (http://www.yamaichi.co.jp/e/
index.shtml)
Emulator main unit
Emulator debugger
Converter board
(Choose according to the foot
pattern of your target system.
For details, see "3.7 Connecting
the Target System" on page
36.)
PC4701
M3T-PD38
For 80-pin 0.8-mm-pitch QFP (80P6N-A):
- M3T-DUMMY80
- M3T-FLX-80NRA
- M3T-FLX-80LCC (included) and IC61-080-081 (included)
For 80-pin 0.5-mm-pitch QFP (80P6Q-A):
- M3T-FLX-80NSD
- M3T-FLX-80LCC (included) and M3T-80LCC-QSD
Item
Emulation pod main unit M37641T2-RPD-E
Flexible cable FLX120-RPD for connecting PC4701
Converter board M3T-FLX-80LCC for 80-pin LCC package
IC socket IC61-080-081 (80-pin 0.8-mm-pitch) made by Yamaichi Electronics Co., Ltd.
Oscillator circuit board OSC-2 (bare-board)
Evaluation MCU M37643M8-XXXFS
Hardware tool user registration FAX sheet (English)
Hardware tool user registration FAX sheet (Japanese)
M37641T2-RPD-E user's manual (this manual)
M37641T2-RPD-E user's manual (Japanese)
Quantity
1
1
1
1
1
1
1
1
1
1
