MIDI implementation
V-Accordion r
71
MIDI implementation
1. Received data
■ Channel Voice Messages
● Note off
● Note on
● Control Change
• The value specified by a Control Change message is not reset by a Program
Change, etc.
❍ Bank Select (Controller number 0, 32)
• Only for Free Bass.
❍ Expression (Controller number 11)
• This adjusts the volume of a Part. It can be used independently from Volume
(CC07) messages. Expression messages are used for musical expression within
a performance, e.g., expression pedal movements, crescendo and decrescendo.
❍ Program Change
■ System Realtime Messages
❍ Active Sensing
• When Active Sensing is received, the FR-3x starts monitoring the intervals of all
further messages. While monitoring, if the interval between messages exceeds
420 ms, the same processing will be carried out as when All Sounds Off, All Notes
Off and Reset All Controllers are received, and message interval monitoring will
be halted.
2. Transmitted data
■ Channel Voice Messages
● Note off
● Note on
● Control Change
❍ Bank Select (Controller number 0, 32)
❍ Mdulation number (Controller number 01)
❍ Expression (Controller number 11)
• This adjusts the volume of a Part. Expression messages are used for musical ex-
pression within a performance, e.g., expression pedal movements, crescendo and
decrescendo.
❍ Program Change
❍ Pitch Bend Change
■ System Realtime Messages
❍ Active Sensing
❍ Start
❍ Stop
3. Program change messages
Status 2nd byte 3rd byte
8nH kkH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
kk = note number: 00H~7FH (0~127)
vv = note off velocity: 00H~7FH (0~127)
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
kk = note number: 00H~7FH (0~127)
vv = note on velocity: 01H~7FH (1~127)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H~FH (Ch.1~16)
mm = Bank number MSB: 00H~7FH
ll = Bank number LSB: 00H~7FH
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
vv = Expression: 00H~7FH (0~127)
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H~FH (Ch.1~16)
pp = Program number: See “3. Program change messages”.
For the Sets, see “SET RX” on p. 72
Status
FEH
Status 2nd byte 3rd byte
8nH kkH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
kk = note number: 00H~7FH (0~127)
vv = note off velocity: 00H~7FH (0~127)
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
kk = note number: 00H~7FH (0~127)
vv = note on velocity: 01H~7FH (1~127)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H~FH (Ch.1~16)
mm = Bank number MSB: 00H~7FH
ll = Bank number LSB: 00H~7FH
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
vv = Modulation depth: 00H~7FH (0~127)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
vv = Expression: 00H~7FH (0~127)
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H~FH (Ch.1~16)
pp = Program number: 00H~7FH: program no. 1~128
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H~FH (Ch.1~16)
mm, ll= Pitch Bend value 00 00H~40 00H~7F 7FH (–8192~0~+8191)
Status
FEH
Transmitted about every 250ms.
Status
FAH
This message is transmitted when the [METRONOME] switch is
pressed after assigning the “2” option to the “MFn” parameter.
Status
FCH
This message is transmitted when the [METRONOME] switch is
pressed after assigning the “2” option to the “MFn” parameter.
CC00 CC32 Program
Change
Register Name
TREBLE REGISTER TX/RX
0 0 1 1 Bassoon
0 0 2 2a Bandon
0 0 3 2b Cello
0 0 4 3 Harmon
0 0 5 4 Organ
0 0 6 5a Accord
0 0 8 5b Master
0 0 11 6a Tremolo
0 0 9 6b Musette
0 0 7 7 Violin
0 0 13 8 Oboe
0 0 12 9a Clarinet
0 0 10 9b Celeste
0 0 14 0 Piccolo
ORCHESTRA (Treble) TX/RX
0 0 1 1 Trombone
0 0 2 2 Trumpet
0 0 3 3 T Sax
0 0 4 4 A Sax
0 0 5 5 Clarinet
0 0 7 6 Harmonica
0 0 9 7 Violin
0 0 11 8 Flute
0 0 26 9 El. Piano
0 0 20 0 Strings
ORGAN (Treble) TX/RX (without rotary effect)
0 0 27 1 Perc Jazz
0 0 28 2 Jazz Ballad
0 0 29 3 Distort Organ
0 0 30 4 Full Organ
0 0 31 5 Overdr Organ
0 0 32 6 Popular Organ
0 0 33 7 Ligh Jazz
0 0 34 8 Bossa
0 0 35 9 Latin
0 0 36 0 Light Latin
