Loading User Set memories from USB memory (optional)
V-Accordion r
41
Loading User Set memories from
USB memory (optional)
The FR-3x allows you to copy individual Sets from a
USB memory to the four internal “USER” Set locations.
The Set files (with the extension “.ST3”) must first be
copied to a USB memory’s root directory before loading
them into the FR-3x’s “USER” area.
NOTE
Be sure to connect your USB memory before proceeding. See
“Connecting an optional USB memory” on p. 34.
1. Press and hold down the [SET] register.
The display shows the name of the last parameter
you selected.
2. Use treble register [3] or [4] (PARAM LIST)
to select “USt” (User Set).
3. Use treble registers [1] and [2] (VALUE) to
select the file number of the Set you want
to load.
If the USB memory doesn’t contain any Set files, the
display will show “---” instead of a number.
4. Press treble register [7] (ENTER) to confirm
your selection.
The FR-3x suggests “USER” memory “1” as target for
the Set file.
5. Use treble registers [1] and [2] (VALUE) to
select the desired target memory (1~4).
6. Press treble register [7] (ENTER) to load the
selected Set.
The display shows “lod” (Load), then “don” (Done) to
indicate that the file was loaded successfully. Next,
the FR-3x returns to the main page.
NOTE
See “Selecting Sets” on p. 25 for how to recall the settings
of the desired User Set.
Loading new sounds from a USB
memory (optional)
The FR-3x allows you to add new sounds to the internal
sounds. The new sounds (files with the “.Bl3” extension)
must be copied to a USB memory’s root directory, after
which you can load them with the FR-3x. “Loading”
means that they will be copied to a permanent internal
memory area. There are two such memory areas (“1”
and “2”).
NOTE
Be sure to connect your USB memory before proceeding. See
“Connecting an optional USB memory” on p. 34.
1. Press and hold down the [SET] register.
The display shows the name of the last parameter
you selected.
2. Use treble register [3] or [4] (PARAM LIST)
to select “Snd” (Sound).
3. Use treble registers [1] and [2] (VALUE) to
select the number of the sound file you
want to load from the connected USB mem-
ory.
If the USB memory doesn’t contain any sound files,
the display will show “---” instead of a number.
4. Press treble register [7] (ENTER) to confirm
your selection.
The FR-3x suggests memory area “1” as target for the
selected file.
5. Use treble registers [1] and [2] (VALUE) to
select the desired target memory area (1 or
2).
6. Press treble register [7] (ENTER) to load the
selected sound set.
The display shows “lod” (Load) to indicate that the
data are being loaded (this may take 1.5 minutes).
Next, the “don” (Done) message appears to signal
that the file was loaded successfully.
NOTE
The new sounds can only be used if you also load the asso-
ciated User Sets and select one of those.
Ust
Snd
