EYE-Q TM Autoconvergence
TOUCH-UP
When TOUCH-UP is selected, only the static convergence of the
currently selected source will be carried out automatically. Follow
the steps below to select:
Highlight TOUCH-UP by pushing up or down keys of the con-
trol disc;
Press the button to start up the static convergence.
If the process is successfully completed, the projector will return to
image display of the current source.
ALIGN ON CURRENT SOURCE
When ALIGN is selected, the automatic convergence on the current
memory bank will be carried out automatically, starting from the
existing settings.
By projecting alternately red and blue line, 25 convergence areas
are aligned to the green pattern.
Follow the steps below to select:
Highlight ALIGN below ON CURRENT SOURCE by push-
ing up or down keys of the control disc;
Press the button to start up the automatic conver-
gence of the entire screen.
If the process is successfully completed, the projector will return to
image display of the current source.
Use this option when the convergence is close to proper alignment.
ALIGN FROM MIDPOSITION ON CURRENT SOURCE
When ALIGN FROM MIDPOSITION is selected, the automatic
convergence on the current source will be carried out automatical-
ly, but starting from the mid-position settings.
By projecting alternately red and blue lines, 25 convergence areas
are aligned to the green pattern.
Follow the steps below to select:
Highlight ALIGN FROM MIDPOSITION by pushing up or
down keys of the control disc;
Press the button to start up the automatic conver-
gence of the entire screen.
If the process is successfully completed, the projector will return to
image display of the current source.
Use this option when the convergence is far from proper alignment.
ADJUSTMENT MODE
Select a path from below:
EYE-Q
GUIDED
RANDOM ACCESS
INSTALLATION
SERVICE
