5 connections, Vcr hdtv player – Runco DTV-940/943 User Manual
Page 15
3-5
Connections
GENERAL ACCESS
SHARPNESS
TINT
COLOR
BRIGHTNESS
CONTRAST
5
6
3
4
1
2
Enter ADJUST
Select with ,
or
then
FROM LOCAL KEYPAD
RS232 IN
RS232 OUT
IR
COMM PORT
REMOTE
R
G(s)
B H V VIDEO S - VIDEO
This device complies with part 15 of
the FCC rules. Operation is subject to
following two conditions (1), This
device may not cause harmful inter-
ferance, and (2) this device must
accept any interferance received
including interferance that may cause
undesired operation.
VCR HDTV player
12v Fuse
Mask Screen
SOURCE SELECTION
SELECT AN INPUT
FROM BELOW:
RGB
S-VIDEO
VIDEO
COMPONENT VIDEO
Select with
or
then
FROM RCU
RS232 IN
RS232 OUT
IR
COMM PORT
REMOTE
R
G(s)
B H V VIDEO S - VIDEO
This device complies with part 15 of
the FCC rules. Operation is subject to
following two conditions (1), This
device may not cause harmful inter-
ferance, and (2) this device must
accept any interferance received
including interferance that may cause
undesired operation.
VCR HDTV player
12v Fuse
Mask Screen
Connecting a Component source.
(R-Y)Y(B-Y) analog input terminals with sync input or
with sync on the luminance (Y) input. The projector detects
automatically where the sync signal is located.
(R-Y)Y(B-Y)S or (R-Y)Ys(B-Y) input selection
a. With the RCU: Select “Component” in the Source Selec-
tion Menu
b. With the local keypad :
(to gain access to the local keypad, see ‘Local key-
pad’ in chapter ‘Location and function of controls’.)
-Press ADJUST key, the General access menu is dis-
played on the screen.
-Use the control disk to highlight 5.
-Press ENTER to select the highlighted source.
Connecting a Component source with Tri-level sync.
(R-Y)Y(B-Y) analog input terminals with Tri-level
sync input or with Tri-level sync on the luminance
input.
SOURCE SELECTION
SELECT AN INPUT
FROM BELOW:
RGB
S-VIDEO
VIDEO
COMPONENT VIDEO
Select with
or
then
FROM RCU
