6-2
Random Access Adjustment Mode
Selecting Setup Pattern
If an external source is connected to the projector, this menu will be displayed. Push the con-
trol disc up or down to highlight the desired setup pattern and then press ENTER.
Genlocked pattern : internally generated cross hatch pattern, locked on the external source.
NOTE: The Genlocked pattern will run at the scan rate of the internal scaler unless an exter-
nal Hi-Res RGB or component source is used.
Internal # pattern : internally generated cross hatch pattern and locked on internal generat-
ed sync signals. (no external source necessary)
If no external source is connected to the projector, the internal cross hatch pattern menu will
be displayed.
Note: The menus in the manual are created for the internal scaler, and the ‘Genlocked Pat-
tern’ is selected.
Internal Cross Hatch Pattern
The internal # pattern menu will be displayed if the internal cross hatch pattern has been
selected or if no source is connected to the projector.
The table below lists the 8 fixed factory preset frequencies available. Another 8 blocks are
custom programmable.
Push the control disc up or down to highlight the desired cross hatch frequency. Push the
control disc to the left or to the right to scroll to another page. Press ENTER if the desired
block is selected.
15.6/50
PAL/SECAM
15.7/60
NTSC
31.2/50
EDTV
31.5/60
IDTV
31.2/50
HDTVEUREKA
31.5/60
HDTV ATV
33.7/60
HDTV HIVISION
15.8/60
EGA 1
21.8/60
EGA 2
31.5/60
VGA 3
31.5/70
XGA 1,2
35.5/97
VGA 4
44.2/70
SUPER VGA 2
48.5/60
SUPER VGA 1
61.0/76
SUPER VGA 3
63.9/76
APOLLO
ENTER continues to Random Access Adjustment Mode or
Internal # Pattern Selection.
EXIT returns to Path Selection menu.
ADJUST returns to Operational mode.
ENTER continues to the Random Access Adjustment Mode.
EXIT returns to the Setup Pattern Selection menu.
