Runco DTV-940/943 User Manual
Page 44
7-11
Service Mode
I2C Diagnostics
Highlights ‘I2C Diagnostics’ by pushing the control disc up or down and press
ENTER.
The I2C diagnostics menu gives an overview of the I2C failure inside the projec-
tor.
To scroll through the failure list, push the control disc up or down.
The I2C address, IC number and module name will be given in I2C diagnostic
menu.
When no errors are detected, the following message will appear on the screen :
“No errors on i2c-bus detected”.
SERVICE MODE
PROJECTOR SET-UP
MEMORY MANAGEMENT
COMMON SETTINGS
Select with
then
or
12C DIAGNOSTICS
12C DIAGNOSTICS
Failures :
addr IC number
mod.name
48H IC200 DECODER
Scroll with or
then
