Function 7 - Assign Bank
This function is used to setup the Pitch Play Assign Banks. There are four Assign banks, A,
B, C, & D. Range = ‘AA’ to ‘Ad’. This feature places a drum sound in the centre of a one
octave range of undefined MIDI note numbers allowing the drums pitch to follow a musical
scale.
Assign Bank Display Ident. MIDI Note Range
Bank A ‘AA’ 12 ( C-1 ) - 23 ( B-1 )
Bank B ‘Ab’ 84 ( C5 ) - 95 ( B5 )
Bank C ‘AC’ 96 ( C6 ) - 107 ( B6 )
Bank D ‘Ad’ 108 ( C7 ) - 120 ( C8 )
Press the ‘ASSIGN BANK’ and the display alternates between:
Display Ident. Value ( Bass Drum )
Use the ‘-’ and ‘+’ buttons to change the value ( drum code ). This setting can be saved with a program. See ‘Writing a pro-
gram into memory’ on page 13. Press the ‘ASSIGN BANK’ button again to select banks B, C and D. The display will loop
back to ‘AA’ after ‘Ad ‘
Utility Mode
Assign Bank
39
MIDI RX CH
MIDI TX CH
PROGRAM
EDIT WRITE
UTILITY
SAVE
MIDI RX CH
MIDI TX CH
PROGRAM
EDIT WRITE
UTILITY
SAVE
