Use the ‘-’ and ‘+’ buttons to change the value. As a secondary visual indication, the rele-
vant ‘Drum Kit’ LED will flash. This setting can be saved with the program. See ‘Writing a
program into memory, on page 13.
NOTE: Because the TR909 has fewer drum sounds than the TR808 ( Conga’s - Maracas - Cowbell etc.) only the drum
sounds common to both units will be moved in this operation. - see the ‘MIDI Percussion Maps’ on page 47.
Function 6 - Output Set
The D Station’s output section consists of a Stereo left/right pair and six Individual outputs which enable a drum sound(s) to
be processed separately.
This function is used to select either a drum sound’s position in the ‘stereo field’ or one of the six individual mono outputs.
OUTPUT DISPLAY IDENT OUTPUT DISPLAY IDENT
Individual O/P 1 01 Stereo O/P Left 3 L3
Individual O/P 2 02 Stereo O/P Left 2 L2
Individual O/P 3 03 Stereo O/P Left 1 L1
Individual O/P 4 04 Stereo O/P Centre Ct
Individual O/P 5 05 Stereo O/P Right 1 R1
Individual O/P 6 06 Stereo O/P Right 2 R2
Individual O/P 4 04 Stereo O/P Right 3 R3
Stereo O/P Left 4 L4 Stereo O/P Right 4 R4
Utility Mode
Output Set
37
