Drum Sound Controls
The TR808 and TR909 also had differences in their sound editing controls. To give the D
Station enhanced sonic capabilities, the controls in each section will affect both drum kits.
For your reference, the controls of the original units and the D Station’s are as follows:
808 KIT l
D Station l + m
808 KIT BD SN RS HC CH OH CY LT MT HT CB LC MC HC MA CL
LEVEL
l l l l l l l l l l l l l l l l
TUNE m m m m m m l l l m l l l m m
TONE l l l
ATTACK
DECAY
l m l l m m m
SNAPPY l
909 KIT l
D Station l + m
909 KIT BD SN RS HC CH OH CY LT MT HT RC
LEVEL
l l l l l l l l l l l
TUNE l l m m m m l l l l l
TONE l
ATTACK l
DECAY
l l l m l l l m
SNAPPY l
TR808 / TR909
Notes
17
