Roland D Station User Manual

Page 37

Response for tu - to - At - dE - Sn parameters:
‘OF’ - will respond to MIDI Controller data
‘On’ - will respond to MIDI Velocity data
Response for VL parameter:
‘OF’ - has a fixed MIDI Velocity level ( 100 )
‘On’ - will respond to MIDI Velocity data

Press the ‘CONT./VELOCITY’ button once and the display alternates between:

Typical Display Ident.

Value

Use the ‘-’ and ‘+’ buttons to change the value. Press the ‘CONT./VELOCITY’ button again to select ‘to’ ( Tone ) ‘At’
( Attack ) etc. The display will loop back to ‘Tu’ ( tune ) after ‘VL’ ( Velocity ). Use the ‘Drum Select’ function again to change
these settings on another drum sound. This setting can be saved with the program.
NOTE: the ‘VL’ display ident. appears as a ‘UL’ on screen due to limitations of the 7 segment display.

Function 4 - Note-Off Recognition
This function is used to setup a drum sounds response to MIDI Note-Off messages. Normally, when a MIDI Note-On mes-
sage is received a drum sound will play in full ( long decay on a bass drum, cymbal etc.) thus ignoring any Note-Off mes-
sage. When set to recognised ( ‘rE’ ), the duration of the drum sound will be determined by the length of time a note is held

Utility Mode

Note Off Recogn’t’n

MIDI RX CH

MIDI TX CH

PROGRAM

EDIT

WRITE

UTILITY

SAVE
