Operational Procedure
IMPORTANT NOTE: The operating system of the ‘Data Entry’ keypad is different in this
mode ( all of the functions in the Utility mode are visually indicated in small text under the
data entry buttons- see panel diagram on page 8 ). The ‘0’ to ‘9’ buttons are now used to call up ‘sub-directories’ of the
Utility mode and the ‘-’ and ‘+’ buttons used to change their values whilst the display may flash alternatately between a
value and a letter reference code. The nine sub-directories are as follows:
Button Function Display Ident.
1 Drum Select Selected Drum
2 Front Cut ‘FC’
3 Controller / Velocity ‘tu’-’to’-’At’-’dE’-’Sn’-’VL’
4 Note Off Recognition ‘nO’
5 General MIDI ‘Gn’
6 Output Set ‘01’ to ‘r4’
7 Assign Banks ‘AA’-’Ab’-’AC’-’Ad’
8 Distortion ‘dS’
9 Demo ‘dE’
Each drum has a display code which, in connection with the ‘Drum Kit’ select LED’s identifies which drum sound is current-
ly selected or edited. The codes are as follows:
Utility Mode
Operation
