First, use the ‘Drum Select’ function to select the drum sound to be edited. Press the ‘OUT-
PUT SET’ button once - the display alternates between:

Display Ident.( Selected drum )

Value ( Individual output 1 )

Use the ‘-’ and ‘+’ buttons to change the value. Use the ‘Drum Select’ function again to change settings on another drum
sound. This setting can be saved with the program. See ‘Writing a program into memory, on page 13.

Any number of drum sounds can be routed to an Individual output enabling a ‘stack’ of sounds to be processed in a similar
manner.
Example: TR808 Snare - TR909 Snare - TR909 Handclap all routed to output 1 - all treated with the same effect i.e.
Reverb/Compression/Eq etc.
NOTE 1: When a drum sound is routed to an Individual output it will be removed from the Stereo left/right mix and
Headphone outputs.
NOTE 2: The stereo output ‘Pan’ setting can also be accessed via MIDI. This feature allows real-time, dynamic changes to
be made during a performance. See the ‘Controller Map’ section on page 42.

Utility Mode

Output Set

MIDI RX CH

MIDI TX CH

PROGRAM

EDIT

WRITE

UTILITY

SAVE
