IP Softphone 2050 Call Control window

24

Hold

To place an active call on hold.

The feature key label for the line on hold displays
a flashing icon to indicate that the call is on hold.

Return to the call by clicking the Line button of
the call on hold.

Release

To terminate an active call.

Line keys

To access one of six programmable Line keys.
These keys can represent line appearances,
DNs, or features.

The communication server provides the labels
that appear on these keys.

Dialpad

To dial a telephone number. Use your mouse
pointer to click the numbers you want to enter.

Directory

To access CS 1000 Directory features.

Depending on how the system administrator sets
up this service, use this button to access
Personal Directory or other server-based
directory services.

You can use CS 1000 Directory features to place
a call. The call is placed on your prime line,
unless you select a different line.

Services

To access a list of network services.

Expand

To access Graphical External Application Server
(GXAS) applications.

Table 1: IP Softphone 2050 components and functions
(Part 3 of 4)

Element

Function
