Ports: DSL
The DSL por t selection shows the state of the DSL line, whether it is up or down and how
many times the Gateway attempted to train. The state should indicate ‘up’ for a working
configuration. If it is not, check the DSL cable and make sure it is plugged in correctly and
not connected to a micro filter. Below is an example:
ADSL Line State: Up
ADSL Startup Attempts: 5
ADSL Modulation: DMT
Datapump Version: 3.22
Downstream Upstream
---------- ----------
SNR Margin: 18.6 14.0 dB
Line Attenuation: 0.4 4.0 dB
Errored Seconds: 14 3
Loss of Signal: 4 4
Loss of Frame: 0 0
CRC Errors: 0 0
Data Rate: 8000 800
