VLAN id – This must be a unique identifying number between 1 and 4095.
•
VLAN Name – A descriptive name for the VLAN.
•
VLAN Protocol – This field is not editable; you can only associate ports with a VLAN.
•
Admin Restricted – If you want to prevent administrative access to the Gateway from
this VLAN, check the checkbox.
Click the
Submit
button.
The
VLAN Port Configuration screen appears.
•
Por t inter faces available for this VLAN are listed in the left hand screen.
Displayed por t inter faces var y depending on the kinds of physical por ts on your Gate-
way, for example, Ethernet, USB, and/or wireless.
Also, if you have multiple wireless SSIDs defined, these may be displayed as well (See
Enable Multiple Wireless IDs on
)
