10GBASE-ZR/ZW XFP specifications 47
ATTENTION
You can configure the XFP to operate in either LAN (Ethernet) or WAN (SONET)
mode, depending on the module (8683XLR is a LAN-only module, and 8683XZR
is a LAN/ WAN module). Model numbers ending in R denote a LAN interface;
model numbers ending in W denote a WAN interface.
CAUTION
Risk of equipment damage
To prevent damage to the optical receiver, ensure that at least 11
dB of attenuation is present between the transmit and receive
ports.
Table 17
10GBASE-ZR/ZW XFP specifications
Parameter Specifications
Line rate (nominal) 10GBASE-ZR 10.3125 Gbit/s ±100 ppm
10GBASE-ZW 9.95328 Gbit/s ±20 ppm
MTBF 675 000 hours
Distance Up to 80 km
Link optical power budget 24 dB
Maximum transmitter and dispersion penalty 3.0 dB at 80 km (G.652 fiber)
Transmitter characteristics
Center wavelength range 1530 to 1565 nm; nominal 1550 nm
Side mode suppression ratio (minimum) 30 dB
Average launch power 0 to 4.0 dBm
Optical modulation amplitude (minimum) -1.7 dBm
Average launch power of OFF transmitter
(maximum) -30 dBm
Extinction ratio (ER) minimum 3.5 dB end of life
maximum 7.0 dB start of life
RIN
12
OMA (maximum) -128 dB/Hz
Maximum optical return loss tolerance -26 dB
Maximum transmitter reflectance -12 dB
Receiver characteristics
Wavelength range 1280 to 1575 nm.
Sensitivity specified for 1530 to 1565 nm.
Signaling speed (nominal) 10GBASE-ZR 10.3125 Gbit/s ± 100 ppm
10GBASE-ZW 9.95328 Gbit/s ± 100 ppm
